Запчасти Komatsu 445FXL-1 T-A РАБОЧЕЕ ОБОРУДОВАНИЕ ТРУБКА ЛИНИИ СТАНДАРТН. ОСНОВН. ГИДРОЛИНИЯ СТРЕЛЫ И ЧАСТИ КОРПУСА РАБОЧЕЕ ОБОРУДОВАНИЕ

1

BOOM, STANDARD MAIN ( SEE FIG. T1000- 01A0 )

SN: A10001--UP

-1шт.

2

82719KF

BUSHING (305IDX4.00DX3.25LG)

SN: A10001--UP

2шт.

3

12365KF

SPACER, BASE (3 IN x 4-1/4 IN)

SN: A10001--UP

3шт.

4

11706KF

BUSHING (3 IN ID x 3-1/2 IN OD X 4-1/4 IN)

SN: A10001--UP

1шт.

5

15563KF

NUT, NYLOCK (5/8 IN)

SN: A10001--UP

10шт.

6

10771KF

WASHER, SAE FLAT (5/8 IN PL GR9)

SN: A10001--UP

12шт.

7

15672KF

STUD (5/8 IN x 6-1/4 IN)

SN: A10001--UP

10шт.

8

12249

CLAMP, CASE DRAIN HOSE

SN: A10001--UP

8шт.

9

26904KF

CLAMP, SADDLE (1 IN x 1 IN x 1 IN)

SN: A10001--UP

8шт.

10

15236KF

CLAMP, SADDLE TOP TUBE (3/4 IN x 1 IN)

SN: A10001--UP

12шт.

11

85096KF

TUBE, BENT (1 IN x 154 IN)

SN: A10001--UP

8шт.

N/I

15225KF

CONNECTOR, STRAIGHT (FF1852T-1616S)

SN: A10001--UP

2шт.

12

85294KF

TUBE, BENT (3/4 IN x 155 IN)

SN: A10001--UP

2шт.

13

10783KF

BOLT (1/2 IN x 1 IN)

SN: A10001--UP

1шт.

14

10804KF

WASHER, FLAT (1/2 IN)

SN: A10001--UP

3шт.

15

80496KF

GUARD, STANDARD STICK ARM HOSE

SN: A10001--UP

1шт.

|$18

OR

16

-1шт.

15

27749KF

GUARD, DROOP NOSE ARM HOSE

SN: A10001--UP

1шт.
