Запчасти Komatsu 445FXL-1 T-A ТЕЛЕСКОПИЧЕСК. РУКОЯТЬ РАБОЧЕЕ ОБОРУДОВАНИЕ

|$0

26697KF

ARM, TELESCOPIC

SN: A10001--UP

1шт.

1

21062

WELDMENT, SLIDE ARM

SN: A10001--UP

1шт.

2

23528KF

PIN (1.75 IN x 10.75 IN)

SN: A10001--UP

1шт.

|$18

OR

3

-1шт.

2

00100269KF

PIN (45 MM x 8.44 IN)

SN: A10001--UP

1шт.

3

19613KF

WASHER, SAE FLAT (1-1/2 IN EXTRA THICK)

SN: A10001--UP

1шт.

4

20811KF

NUT, NYLOCK (1-1/2 IN - 12 JAM LOW HT)

SN: A10001--UP

1шт.

5

10815KF

NUT, LOCK (1/2 IN)

SN: A10001--UP

1шт.

6

10836KF

BOLT (1/2 IN x 5-1/2 IN)

SN: A10001--UP

1шт.

7

21063

WELDMENT, SLIDE ARM STINGER

SN: A10001--UP

1шт.

8

21064

SHACKLE, SCREW PIN ANCHOR

SN: A10001--UP

1шт.

9

21065

PLATE, BULKHEAD STINGER

SN: A10001--UP

1шт.

10

NSS

WELDMENT, TELESCOPIC

SN: A10001--UP

1шт.

11

18564KF

BUSHING (3-1/2 IN x 4-1/4 IN)

SN: A10001--UP

2шт.

12

85095KF

SPACER, BASE (3-1/2 IN x 3 IN)

SN: A10001--UP

1шт.

13

19117KF

BUSHING (1-3/4 IN)

SN: A10001--UP

2шт.

|$19

OR

16

-1шт.

13

19118KF

BUSHING (45 MM)

SN: A10001--UP

2шт.
