Запчасти Komatsu 445FXL-1 D7-A CONTINUOUS ROTATION ТОПЛИВН. СИСТЕМА ПОВОРОТН. КОЛЛЕКТОР - ДВИГАТЕЛЬ ТОПЛИВН. БАК. AND КОМПОНЕНТЫ

1

24928KF

HOSE ASSEMBLY (2063-08-080S-08J9-W WS125)

SN: A10001--UP

1шт.

2

24380KF

HOSE ASSEMBLY (2021-08-08JS-08J9)

SN: A10001--UP

1шт.

3

82025KF

BRACKET, FUEL FILTER

SN: A10001--UP

1шт.

4

15542KF

BOLT (3/8 IN x 3/4 IN)

SN: A10001--UP

4шт.

5

15528KF

WASHER, SAE FLAT (3/8 IN)

SN: A10001--UP

8шт.

6

10402KF

BOLT (3/8 IN x 1-1/4 IN)

SN: A10001--UP

2шт.

7

10813KF

NUT, LOCK (3/8 IN)

SN: A10001--UP

2шт.

|$7

4A1-04-10040

FILTER ASSEMBLY, REMOTE FUEL

SN: A10001--UP

1шт.

8

4A1-04-10030

FILTER, REMOTE FUEL

SN: A10001--UP

1шт.

9

4A1-04-10020

DRAIN, FUEL FILTER

SN: A10001--UP

1шт.

10

00830050

FITTING

SN: A10001--UP

1шт.

11

82513KF

HOSE ASSEMBLY (2073-08-080S-08J9-W)

SN: A10001--UP

1шт.

12

15457KF

CONNECTOR, STR (8 ORFS MX6 ORB M)

SN: A10001--UP

1шт.

13

00830227

FITTING

SN: A10001--UP

1шт.

14

16297KF

ELBOW, 90 DEGREE SWIVEL (FF2098T-0808S)

SN: A10001--UP

3шт.

15

22405KF

ELBOW, 90 DEGREE (8-6 C50L0-S)

SN: A10001--UP

1шт.

16

07270-00843

HOSE, 430 MM DRAIN

SN: A10001--UP

1шт.
