Запчасти Komatsu 445FXL-1 T7-A ТЕЛЕСКОПИЧЕСК. ЦИЛИНДР РУКОЯТИКРЕПЛЕНИЕ РАБОЧЕЕ ОБОРУДОВАНИЕ

1

CYLINDER, TELESCOPIC ARM ( SEE FIG. T0170-01A0 )

SN: A10001--UP

-1шт.

2

10783KF

BOLT (1/2 IN x 1 IN)

SN: A10001--UP

1шт.

3

15534KF

WASHER, SAE FLAT (1/2 IN)

SN: A10001--UP

1шт.

4

21091

PIN, EXTENSION CYLINDER

SN: A10001--UP

1шт.

|$4

12270KF

CLAMP, VERMATIC

SN: A10001--UP

1шт.

5

NSS

PLATE

SN: A10001--UP

1шт.

6

NSS

CLAMP

SN: A10001--UP

2шт.

7

NSS

BOLT

SN: A10001--UP

2шт.

8

23501

HOSE ASSEMBLY (4081-12-160S-12PS)

SN: A10001--UP

1шт.

9

10739KF

BOLT (1/2 IN x 1-1/2 IN)

SN: A10001--UP

2шт.

10

21093

WASHER, RETAINING

SN: A10001--UP

2шт.

11

21094

BUSHING, TRUNNION

SN: A10001--UP

2шт.

12

15565KF

BOLT (1/2 IN x 2-1/2 IN)

SN: A10001--UP

4шт.

13

21098

BLOCK, TRUNNION

SN: A10001--UP

2шт.

14

15225KF

CONNECTOR, STRAIGHT (FF1852T-1616S)

SN: A10001--UP

1шт.
