Запчасти Komatsu 445FXL-1 T-A STICK ЦИЛИНДР РУКОЯТИ РАБОЧЕЕ ОБОРУДОВАНИЕ

|$0

4A1-6C-10410

CYLINDER ASSEMBLY, STICK ARM

SN: A10001--UP

1шт.

1

26152KF

ASSEMBLY KIT, BARREL

SN: A10001--UP

1шт.

2

11706KF

BUSHING (3 IN ID x 3-1/2 IN OD X 4-1/4 IN)

SN: A10001--UP

2шт.

3

19956KF

BOLT, CYLINDER ROD

SN: A10001--UP

1шт.

4

NSS

RING, PISTON WEAR

SN: A10001--UP

2шт.

5

NSS

RING, PISTON SQUARE

SN: A10001--UP

1шт.

6

NSS

RING, PISTON CHEM-CAST

SN: A10001--UP

1шт.

7

NSS

RING, PISTON WEAR

SN: A10001--UP

1шт.

8

NSS

O-RING, PISTON

SN: A10001--UP

1шт.

9

4A1-6C-10430

PISTON ASSEMBLY

SN: A10001--UP

1шт.

10

NSS

RING, ROD BEARING WEAR

SN: A10001--UP

1шт.

11

NSS

O-RING, ROD BEARING

SN: A10001--UP

1шт.

12

NSS

RING, ROD BEARING BACK-UP

SN: A10001--UP

1шт.

13

4A1-6C-10420

HEAD, CYLINDER

SN: A10001--UP

1шт.

14

4A1-6C-10030

BOLT

SN: A10001--UP

12шт.

15

NSS

U-CUP, ROD BEARING

SN: A10001--UP

1шт.

16

NSS

WIPER, ROD

SN: A10001--UP

1шт.

17

24565KF

ROD ASSEMBLY

SN: A10001--UP

1шт.

18

11706KF

BUSHING

SN: A10001--UP

1шт.

19

10704KF

FITTING, GREASE

SN: A10001--UP

1шт.

20

4A1-6C-10040

WASHER

SN: A10001--UP

12шт.

21

4A1-30-10280

WASHER

SN: A10001--UP

1шт.

|$22

24568KF

REPAIR KIT, MAIN BOOM SEAL

SN: A10001--UP

1шт.

|$23

4A1-6C-10460

RING, PISTON

SN: A10001--UP

1шт.

|$24

4A1-6C-10480

PACKING, PISTON

SN: A10001--UP

2шт.

|$25

4A1-6C-10470

RING, WEAR

SN: A10001--UP

4шт.

|$26

4A1-30-10270

O-RING

SN: A10001--UP

1шт.

|$27

4A1-30-10290

RING, BACK-UP

SN: A10001--UP

2шт.

|$28

4A1-30-10120

SEAL, ROD

SN: A10001--UP

1шт.

|$29

4A1-30-10130

WIPER

SN: A10001--UP

1шт.

|$30

4A1-30-10170

SEAL, BUFFER

SN: A10001--UP

1шт.

|$31

4A1-6C-10070

RING, WEAR

SN: A10001--UP

3шт.

|$32

4A1-6C-10080

O-RING

SN: A10001--UP

1шт.

|$33

4A1-6C-10090

RING, BACK-UP

SN: A10001--UP

1шт.

|$34

34

-1шт.

|$35

F1 - PART INCLUDED IN SERVICE KIT:

35

-1шт.
