Запчасти Komatsu 445FXL-1 R-A УРОВЕНЬING ЦИЛИНДР КРЕПЛЕНИЕ НИЖН.CARRIAGE

1

BASE, 4-WAY LEVELING ( SEE FIG. R4100- 01A0 )

SN: A10001--UP

-1шт.

2

85672KF

PIN, UPPER LEVELING CYLINDER

SN: A10001--UP

2шт.

3

85673KF

SPACER

SN: A10001--UP

4шт.

4

12021KF

WASHER (2.13 x 4 x 0.5 THK)

SN: A10001--UP

2шт.

5

10728KF

NUT, ZINC PLATED NYLOCK (2 IN - 12)

SN: A10001--UP

2шт.

6

CYLINDER, CAB LEVELING ( SEE FIG. R4130- 01A0 )

SN: A10001--UP

-1шт.

7

24447KF

WASHER, BURNED (1.06 IN x 4 IN x 0.5 IN THICK)

SN: A10001--UP

4шт.

8

24446KF

HUB, TAPERED PIN (3 IN)

SN: A10001--UP

4шт.

9

24445KF

PIN, DOUBLE TAPERED (3 IN x 7.88 IN)

SN: A10001--UP

2шт.

10

10733KF

BOLT (1 IN x 3 IN)

SN: A10001--UP

4шт.

|$10

28439KF

SHIM KIT, LOWER LEVEL CLYINDER

SN: A10001--UP

1шт.

11

16636KF

SHIM (0.179 IN THICK)

SN: A10001--UP

-2шт.

|$12

16637KF

SHIM (0.135 IN THICK)

SN: A10001--UP

-2шт.

|$13

16638KF

SHIM (0.075 IN THICK)

SN: A10001--UP

-2шт.

12

28402KF

SPACER (3 IN x 0.60 IN)

SN: A10001--UP

4шт.

13

81184KF

SHIM (0.06 IN THICK)

SN: A10001--UP

4шт.

14

15579KF

WASHER, SAE FLAT (1 IN)

SN: A10001--UP

4шт.
