Запчасти Komatsu 445FXL-1 D-A ТОПЛИВН. БАК. НАПОЛНИТЕЛЬ PORT ТОПЛИВН. БАК. AND КОМПОНЕНТЫ

1

16585KF

CAP, LOCKING FUEL

SN: A10001--UP

1шт.

2

19771KF

LATCH, CAM

SN: A10001--UP

1шт.

|$2

85920KF

COVER ASSEMBLY, FUEL TANK

SN: A10001--UP

1шт.

3

80847KF

COVER, FUEL

SN: A10001--UP

1шт.

4

85919KF

CUSHION, FUEL TANK COVER

SN: A10001--UP

1шт.

5

17114KF

STRAINER, FUEL SYSTEM

SN: A10001--UP

1шт.

6

17115KF

RING, FUEL STRAINER RETAINER SNAP

SN: A10001--UP

1шт.

7

26144KF

GAUGE, FUEL LEVEL

SN: A10001--UP

1шт.

8

80845KF

BRACKET, FUEL COVER

SN: A10001--UP

1шт.

9

10739KF

BOLT (1/2 IN x 1-1/5 IN)

SN: A10001--UP

4шт.

10

15534KF

WASHER, SAE FLAT (1/2 IN)

SN: A10001--UP

5шт.

11

10815KF

NUT, LOCK (1/2 IN)

SN: A10001--UP

1шт.

12

26145KF

COVER, FUEL TANK WITH CAP ADAPTER AND GAUGE PORT

SN: A10001--UP

1шт.

13

15600KF

O-RING (8 IN DIA)

SN: A10001--UP

2шт.
