Запчасти Komatsu 445FXL-1 R-A -WAY УРОВЕНЬING ОСНОВ. НИЖН.CARRIAGE

1

12021KF

WASHER (2.13 x 4 x 0.5 THK)

SN: A10001--UP

2шт.

2

10728KF

NUT, ZINC PLATED NYLOCK (2 IN - 12)

SN: A10001--UP

2шт.

3

11706KF

BUSHING (3 IN ID x 3-1/2 IN OD X 4-1/4 IN)

SN: A10001--UP

4шт.

4

12352KF

HUB, TAPER (1-1/4 IN - 3 IN PIN BORE)

SN: A10001--UP

2шт.

5

81632KF

PIN (3 x 11.75 LG -THD 2-12)

SN: A10001--UP

1шт.

6

12115KF

CAP, TAPER HUB

SN: A10001--UP

2шт.

7

12116KF

LOCK, CENTER TAPER HUB BOLT

SN: A10001--UP

2шт.

8

15565KF

BOLT (1/2 IN x 2-1/2 IN)

SN: A10001--UP

12шт.

9

15552KF

BOLT (1 x 2-1/2 IN)

SN: A10001--UP

2шт.

10

12020KF

PLATE, SLACK ADJUSTMENT

SN: A10001--UP

1шт.

11

15671KF

NUT, JAM (1 IN)

SN: A10001--UP

2шт.

12

15581KF

SCREW, SET (1 IN x 2.93 IN - CHAMFERED END)

SN: A10001--UP

2шт.

13

83569KF

WELDMENT, INTERMEDIATE LEVELER

SN: A10001--UP

1шт.

14

81633KF

PIN (3 x 11 LG THD 2-12)

SN: A10001--UP

1шт.

15

26105KF

CASTING, LOWER TURNTABLE

SN: A10001--UP

1шт.

16

15534KF

WASHER, SAE FLAT (1/2 IN)

SN: A10001--UP

12шт.
