Запчасти Komatsu 445FXL-1 R-A ОПОРНЫЙ КАТОК ОДНОБОРТН. НИЖН.CARRIAGE

|$0

208-30-00711

SINGLE FLANGED TRACK ROLLER

SN: A10001--UP

6шт.

1

208-30-76611

ROLLER, SINGLE

SN: A10001--UP

1шт.

2

208-30-56130

SHAFT

SN: A10001--UP

1шт.

3

207-30-53140

BUSHING

SN: A10001--UP

2шт.

4

208-30-76650

COLLAR

SN: A10001--UP

1шт.

5

208-30-76660

COLLAR

SN: A10001--UP

1шт.

6

207-30-53160

PIN

SN: A10001--UP

2шт.

|$7

207-30-00101

SEAL ASSEMBLY, FLOATING

SN: A10001--UP

2шт.

7

NSS

SEAL

SN: A10001--UP

2шт.

8

NSS

O-RING

SN: A10001--UP

2шт.

9

208-30-56170

O-RING

SN: A10001--UP

2шт.

10

20Y-30-16330

PLUG

SN: A10001--UP

1шт.

11

BOLT ( SEE FIG. R0200-01A0 )

SN: A10001--UP

-1шт.

12

WASHER ( SEE FIG. R0200-01A0 )

SN: A10001--UP

-1шт.
