Запчасти Komatsu 445FXL-1 R-A ЗАЩИТА ГУСЕН. РАМЫS И КРЫШКИ НИЖН.CARRIAGE

1

10739KF

BOLT (1/2 IN x 1-1/2 IN)

SN: A10001--UP

2шт.

2

15534KF

WASHER, SAE FLAT (1/2 IN)

SN: A10001--UP

10шт.

3

10815KF

NUT, LOCK (1/2 IN)

SN: A10001--UP

8шт.

4

82465KF

SPRING, AIR

SN: A10001--UP

1шт.

5

10705KF

BOLT (1/2 IN x 5 IN)

SN: A10001--UP

2шт.

6

16403KF

BRACKET, HINGE

SN: A10001--UP

2шт.

7

82480KF

PLATE, BULKHEAD

SN: A10001--UP

1шт.

8

26287KF

BOLT (1/2 IN x 1-1/4 IN)

SN: A10001--UP

4шт.

9

12335KF

COVER, FRAME CLEAN OUT HOLE

SN: A10001--UP

1шт.

10

15550KF

WASHER, SAE FLAT (3/4 IN)

SN: A10001--UP

4шт.

11

10839KF

BOLT (3/4 IN x 1-1/2 IN GRADE 9)

SN: A10001--UP

4шт.

12

19771KF

LATCH, CAM

SN: A10001--UP

1шт.

13

82119KF

COVER, TOOLBOX

SN: A10001--UP

1шт.

14

NSS

BRACKET, WELDMENT

SN: A10001--UP

1шт.
