Запчасти Komatsu 445FXL-1 P-A ГУСЕНИЦЫ КОРПУС ПРИВОДА ДРЕНАЖН. ТРУБЫ АККУМУЛЯТОР - КОРПУС ДРЕНАЖН. НИЖНЯЯ ГИДРОЛИНИЯ И ЛИНИЯ ХОДА

1

28910KF

HOSE ASSEMBLY (2094-12-120S-1204)

SN: A10001--UP

1шт.

2

4A1-60-10220

ACCUMULATOR, 15 PSI

SN: A10001--UP

2шт.

|$27

OR

2

-1шт.

3

28912KF

ACCUMULATOR, 30 PSI

SN: A10001--UP

2шт.

3

28849KF

MANIFOLD, ACCUMULATOR

SN: A10001--UP

2шт.

4

83553KF

HOSE ASSEMBLY (2026-12-120S-120S-W)

SN: A10001--UP

1шт.

|$28

OR

6

-1шт.

5

83554KF

HOSE ASSEMBLY (2028-12-120S-120S-W)

SN: A10001--UP

1шт.

5

82960KF

HOSE ASSEMBLY (2038-12-120S-12J4-W WS150)

SN: A10001--UP

2шт.

6

20484

HOSE (4052-08-080S-080SW)

SN: A10001--UP

2шт.

7

20567KF

HOSE ASSEMBLY (4055-08-080S-080SW WS150)

SN: A10001--UP

2шт.

8

15497KF

CONNECTOR, STR (6400-16)

SN: A10001--UP

2шт.

9

28907KF

HOSE ASSEMBLY (2067-12-120S-120S-W WS150)

SN: A10001--UP

2шт.

10

15484KF

ELBOW, 90 DEGREE (6801-16)

SN: A10001--UP

2шт.

11

15226KF

CONNECTOR, STR (FF1852T-1216S)

SN: A10001--UP

2шт.

12

17688KF

ELBOW, 90 DEGREE (FF1868T-1212S)

SN: A10001--UP

3шт.

13

15124KF

CONNECTOR, STR (FF1852T-0406S)

SN: A10001--UP

4шт.

14

15145KF

ELBOW, 90 DEGREE SWIVEL (FF2098T-0404S)

SN: A10001--UP

4шт.

15

15154KF

ELBOW, 90 DEGREE (FF1868T-0810S)

SN: A10001--UP

4шт.

16

4A1-60-10210

ADAPTER, HYDRAULIC

SN: A10001--UP

2шт.

17

MANIFOLD, RETURN LINE (SEE FIG. H0259-01A0)

SN: A10001--UP

-1шт.

18

19471KF

CONNECTOR, STR (ADJUSTABLE)

SN: A10001--UP

2шт.

19

17738KF

GUARD, HOSE (8 IN)

SN: A10001--UP

3шт.

20

08034-20823

BAND, TIE

SN: A10001--UP

9шт.

21

07002-12434

O-RING

SN: A10001--UP

4шт.

22

07040-12412

PLUG (M24 x 14)

SN: A10001--UP

2шт.

23

MOTOR, TRAVEL ( SEE FIG. P0700-01A0 )

SN: A10001--UP

-1шт.

|$29

27

-1шт.

|$30

F2 - PLACE GUARDS AT FRAME TO PROTECT HOSE FROM CONTACT.

29

-1шт.

|$31

F2 - PLACE GUARDS AT FRAME TO PROTECT HOSE FROM CONTACT.

29

-1шт.
