Запчасти Komatsu 445FXL-1 C-A РАДИАТОР/МАСЛООХЛАДИТЕЛЬ СИСТЕМА ОХЛАЖДЕНИЯ

|$0

4A1-03-10310

COOLER ASSEMBLY, RADIATOR/OIL

SN: A10001--UP

1шт.

1

82015KF

CORE, HYDRAULIC OIL COOLER (HOC) ELE MENT

SN: A10001--UP

1шт.

2

82014KF

CORE, RADIATOR (RAD) ELEMENT

SN: A10001--UP

1шт.

3

82013KF

CORE, CHARGE AIR COOLER (CAC) ELEMENT

SN: A10001--UP

1шт.

4

82860KF

BRACKET, MOUNTING

SN: A10001--UP

2шт.

5

82153KF

BRACKET, UPPER

SN: A10001--UP

2шт.

6

4A1-03-10340

BRACKET, SHROUD MOUNTING

SN: A10001--UP

2шт.

7

4A1-03-10320

SHROUD

SN: A10001--UP

1шт.

8

4A1-03-10350

BOLT (3/8 IN x 16 x 1 IN)

SN: A10001--UP

32шт.

9

10802KF

WASHER (0.375 IN)

SN: A10001--UP

64шт.

N/I

4A1-03-10360

NUT (3/8 IN - 16)

SN: A10001--UP

16шт.

N/I

4A1-03-10370

BOLT (3/8 IN x 16 x 1/4 IN)

SN: A10001--UP

16шт.

10

4A1-03-10380

BRACKET, MOUNTING ANGLE

SN: A10001--UP

4шт.

N/I

4A1-03-10270

VALVE, THERMOSTATIC

SN: A10001--UP

1шт.
