Запчасти Komatsu 445FXL-1 K-A FOOT ПЕДАЛЬ УПРАВЛ-Я OPERATORXD S ОБСТАНОВКА И СИСТЕМА УПРАВЛЕНИЯ

1

10821KF

BOLT (5/16 IN x 1/2 IN)

SN: A10001--UP

8шт.

2

15559KF

WASHER, SAE FLAT (5/16 IN)

SN: A10001--UP

12шт.

3

PEDAL, FOOT CONTROL ( SEE FIG. E2000- 01A0 )

SN: A10001--UP

-1шт.

4

18249KF

GUARD, LIGHT

SN: A10001--UP

1шт.

5

11707KF

BOLT (3/8 IN x 1 IN)

SN: A10001--UP

2шт.

6

15528KF

WASHER, SAE FLAT (3/8 IN)

SN: A10001--UP

4шт.

7

27350KF

BRACKET, FOOT CONTROLLER

SN: A10001--UP

1шт.

8

10731KF

BOLT (0.375 IN x 1-1/2 IN)

SN: A10001--UP

2шт.

9

15605KF

BOLT (5/16 IN x 3/4 IN)

SN: A10001--UP

4шт.
