Запчасти Komatsu 445FXL-1 K7-A КОНДИЦ. ВОЗДУХА КОНДЕНСАТОР, МОТОР ВЕНТИЛЯТОРА И DRIER OPERATORXD S ОБСТАНОВКА И СИСТЕМА УПРАВЛЕНИЯ

1

15604KF

BOLT (1/4 IN x 3/4 IN)

SN: A10001--UP

13шт.

2

10756KF

WASHER, LOCK (1/4 IN)

SN: A10001--UP

10шт.

3

10757KF

WASHER, SAE FLAT (1/4 IN)

SN: A10001--UP

24шт.

4

15509KF

NUT, NYLOCK (1/4 IN)

SN: A10001--UP

14шт.

5

10800KF

WASHER, FLAT (1/4 IN)

SN: A10001--UP

8шт.

6

23289KF

MOTOR ASSEMBLY, 24V FAN

SN: A10001--UP

2шт.

7

24050KF

PANEL, AIR CONDITIONER FAN MOUNTING

SN: A10001--UP

1шт.

8

19243

SCREW, FLAT HEAD MACHINE (1/4 IN x 1 IN)

SN: A10001--UP

8шт.

9

16092KF

CONDENSER, AIR CONDITIONER

SN: A10001--UP

1шт.

10

15576KF

BOLT (1/4 IN x 1 IN)

SN: A10001--UP

5шт.

11

18093KF

DRIER, AIR CONDITIONER

SN: A10001--UP

1шт.

12

26845KF

COVER, FAN MOTOR ACCESS

SN: A10001--UP

1шт.
