Запчасти Komatsu 445FXL-1 K-A ПРАВ. ОКНАS OPERATORXD S ОБСТАНОВКА И СИСТЕМА УПРАВЛЕНИЯ

1

16230KF

CHANNEL, WINDOW MOLDING

SN: A10001--UP

1шт.

2

24395KF

WINDOW, LEXAN DOOR

SN: A10001--UP

1шт.

3

10802KF

WASHER (0.375 IN)

SN: A10001--UP

46шт.

4

15507KF

NUT, NYLOCK (0.375 IN)

SN: A10001--UP

46шт.

5

24394KF

FRAME, DOOR WINDOW

SN: A10001--UP

1шт.

6

19023KF

FRAME, R.H. CORNER WINDOW

SN: A10001--UP

1шт.

7

19019KF

WINDOW, LEXAN R.H. CORNER

SN: A10001--UP

1шт.

8

18309KF

BOLT (1/4 IN x 1-1/4 IN)

SN: A10001--UP

4шт.

9

10757KF

WASHER, SAE FLAT (1/4 IN)

SN: A10001--UP

4шт.

10

16811KF

GUARD, LEXAN LIGHT

SN: A10001--UP

1шт.

11

23604KF

LIGHT, 24V FLUSH MOUNT

SN: A10001--UP

1шт.

12

4A1-00-10110

DECAL, HYDRAULIC OIL ISO 32

SN: A10001--UP

1шт.

|$16

OR

12

-1шт.

12

4A1-00-10120

DECAL, HYDRAULIC OIL ISO 46

SN: A10001--UP

1шт.

|$17

OR

14

-1шт.

12

4A1-00-10130

DECAL, HYDRAULIC OIL ISO 68

SN: A10001--UP

1шт.
