Запчасти Komatsu 445FXL-1 K-A OPERATORS КРЕПЛЕНИЕ КАБИНЫ OPERATORXD S ОБСТАНОВКА И СИСТЕМА УПРАВЛЕНИЯ

1

CAB ( SEE FIG. K0200-01A0 )

SN: A10001--UP

-1шт.

2

23387KF

BOLT (1 IN x 6-1/2 IN)

SN: A10001--UP

6шт.

3

15579KF

WASHER, SAE FLAT (1 IN)

SN: A10001--UP

6шт.

4

19369KF

WASHER, CAB MOUNTING BURNED

SN: A10001--UP

6шт.

5

18141KF

ISOLATOR, CAB MOUNTING

SN: A10001--UP

8шт.

6

18253KF

NUT, LOCK (1 IN)

SN: A10001--UP

6шт.

7

4A1-53-10330

BOLT (1-1/2 IN x 8-1/2 IN)

SN: A10001--UP

1шт.

8

19613KF

WASHER, SAE FLAT (1-1/2 IN EXTRA THICK)

SN: A10001--UP

2шт.

9

27865KF

WASHER, RUBBER CAB BOLT (1-1/2 IN)

SN: A10001--UP

3шт.

10

NSS

BRACKET, WELDED SUPPORT

SN: A10001--UP

1шт.

11

19614KF

NUT, LOCK (1-1/2 IN)

SN: A10001--UP

1шт.

12

17918KF

WASHER, ISOLATOR MOUNT (7/8 IN x 3-1/2 IN)

SN: A10001--UP

8шт.

N/I

18142KF

WASHER, CAB MOUNTING ISOLATOR (1/4 IN)

SN: A10001--UP

6шт.
