Запчасти Komatsu 445FXL-1 K-A СТАНДАРТН. OPERATORS СИДЕНЬЕ КРЕПЛЕНИЕ OPERATORXD S ОБСТАНОВКА И СИСТЕМА УПРАВЛЕНИЯ

1

SEAT, OPERATOR ( SEE FIG. K0120-05A0 )

SN: A10001--UP

-1шт.

2

4A1-54-10250

BRACKET, JOYSTICK MOUNTING

SN: A10001--UP

2шт.

3

16133KF

BOLT (6 MM x 16 MM)

SN: A10001--UP

8шт.

4

10757KF

WASHER, SAE FLAT (1/4 IN)

SN: A10001--UP

8шт.

5

24467KF

JOYSTICK

SN: A10001--UP

2шт.

6

16212KF

NUT

SN: A10001--UP

8шт.

7

81672KF

BELT, SEAT (TETHER)

SN: A10001--UP

4шт.

8

15509KF

NUT, NYLOCK (1/4 IN)

SN: A10001--UP

2шт.

9

10800KF

WASHER, FLAT (1/4 IN)

SN: A10001--UP

4шт.

10

15604KF

BOLT (1/4 IN x 3/4 IN)

SN: A10001--UP

2шт.

11

20244KF

BELT, HOSE STRAP (1 IN x 40 IN)

SN: A10001--UP

2шт.

12

10402KF

BOLT (3/8 IN x 1-1/4 IN)

SN: A10001--UP

4шт.

13

15528KF

WASHER, SAE FLAT (3/8 IN)

SN: A10001--UP

4шт.

14

19626KF

BRACKET, SEAT MOUNTING

SN: A10001--UP

1шт.

15

10788KF

NUT, NYLOCK (5/16 IN)

SN: A10001--UP

4шт.

16

10801KF

WASHER, FLAT (5/16 IN)

SN: A10001--UP

4шт.

17

10803KF

WASHER, SAE FLAT (7/16 IN)

SN: A10001--UP

4шт.
