Запчасти Komatsu 445FXL-1 J-A ДВИГАТЕЛЬ ROPS/FOPS ПАНЕЛЬS И РАБОЧ. ОСВЕЩЕНИЕ ОСНОВНАЯ РАМА И ЕЕ ЧАСТИ

1

26028KF

NON-SKID (6 IN x 24 IN)

SN: A10001--UP

1шт.

|$22

OR

1

-1шт.

1

26029KF

NON-SKID (6 IN x 36 IN)

SN: A10001--UP

1шт.

2

10705KF

BOLT (1/2 IN x 5 IN)

SN: A10001--UP

6шт.

3

15534KF

WASHER, SAE FLAT (1/2 IN)

SN: A10001--UP

12шт.

4

20084KF

BOLT (3/8 IN x 1-3/4 IN)

SN: A10001--UP

1шт.

5

15528KF

WASHER, SAE FLAT (3/8 IN)

SN: A10001--UP

8шт.

6

14378KF

COVER, PRE-FILTER CLOSURE

SN: A10001--UP

1шт.

|$8

4A1-54-11260

PANEL ASSEMBLY, ENGINE ROPS/FOPS

SN: A10001--UP

1шт.

N/I

01580-00806

NUT

SN: A10001--UP

2шт.

7

14353KF

PANEL, ENGINE ROPS/FOPS

SN: A10001--UP

1шт.

8

14610KF

FRAME, ENGINE HOUSING

SN: A10001--UP

1шт.

9

10815KF

NUT, LOCK (1/2 IN)

SN: A10001--UP

6шт.

10

10739KF

BOLT (1/2 IN x 1-1/2 IN)

SN: A10001--UP

4шт.

11

23292KF

LIGHT, RECTANGULAR DUAL LAMP

SN: A10001--UP

2шт.

|$23

OR

15

-1шт.

11

26165KF

LIGHT, XENON HID WITH REMOTE BALLAST

SN: A10001--UP

2шт.

12

12150KF

COVER, RADIATOR FILL ACCESS

SN: A10001--UP

1шт.

13

10804KF

WASHER, FLAT (1/2 IN)

SN: A10001--UP

2шт.

14

16849KF

KNOB, STAR

SN: A10001--UP

2шт.

|$20

4A1-46-10110

FRAME, UPPER

SN: A10001--UP

1шт.

15

4A1-46-10120

FRAME, REVOLVING

SN: A10001--UP

1шт.
