Запчасти Komatsu 445FXL-1 H-A ВСПОМОГ. НАСОС PRESSURE ЛИНИЯ COMBINED ПОТОК ГИДРАВЛИКА

1

26967KF

MANIFOLD, COMBINED FLOW

SN: A10001--UP

1шт.

2

19472KF

CONNECTOR, STRAIGHT (6403-12)

SN: A10001--UP

1шт.

3

20923KF

VALVE, CHECK

SN: A10001--UP

1шт.

4

17688KF

ELBOW, 90 DEGREE (FF1868T-1212S)

SN: A10001--UP

1шт.

5

22013KF

HOSE ASSEMBLY (4075-12-120S-1204-W)

SN: A10001--UP

1шт.

6

19128KF

ELBOW, 90 DEGREE (FF1868T-12165)

SN: A10001--UP

1шт.

7

16037KF

TAP, GAUGE PORT (0.025)

SN: A10001--UP

1шт.

|$7

22758KF

CONNECTOR ASSEMBLY, FLANGE PAD (1 IN CODE 61)

SN: A10001--UP

1шт.

8

15377

O-RING (1 IN SF)

SN: A10001--UP

1шт.

9

NSS

FLANGE

SN: A10001--UP

1шт.

10

NSS

WASHER

SN: A10001--UP

4шт.

11

NSS

BOLT

SN: A10001--UP

4шт.

12

ELECTRIC DISC CONTROL COMPENSATOR ( SEE FIG. H5050-01A0 )

SN: A10001--UP

-1шт.

N/I

23213KF

HARNESS, ELECTRIC DISC CONTROL COMPENSA TOR

SN: A10001--UP

1шт.
