Запчасти Komatsu 445FXL-1 H-A 7CC ВСПОМОГ. НАСОС IN ВСАСЫВ. ЛИНИИ ГИДРАВЛИКА

Схема запчастей Komatsu 445FXL-1 - H-A 7CC ВСПОМОГ. НАСОС IN ВСАСЫВ. ЛИНИИ ГИДРАВЛИКА
2
3
4
5
6
1
19
9
8
21
16
15
17
20
7
22
18
10
11
12
13
7
14

Артикул

Название

Примечание

Количество

1

PUMP, IMPLEMENT (SEE FIG. H0301-01A0)

SN: A10001--UP

-1шт.

2

15842KF

FILTER, IMPLEMENT SCREEN

SN: A10001--UP

2шт.

3

16327

BUSHING (3 IN x 2-1/2 IN)

SN: A10001--UP

1шт.

4

15448KF

O-RING (5-1/2 IN OD)

SN: A10001--UP

1шт.

5

22462KF

PLATE, INTERMEDIATE SUCTION PORT

SN: A10001--UP

1шт.

6

22441KF

VALVE, BUTTERFLY SHUT OFF

SN: A10001--UP

1шт.

7

27542KF

CLAMP, STRAP BAND (2-1/2 IN)

SN: A10001--UP

2шт.

8

22639KF

FLANGE, SPLIT (3 IN CODE 61)

SN: A10001--UP

1шт.

9

NSS

O-RING, FLANGE

SN: A10001--UP

1шт.

|$9

21226KF

FLANGE KIT, SPLIT (2 IN CODE 61)

SN: A10001--UP

1шт.

10

NSS

O-RING, FLANGE

SN: A10001--UP

1шт.

11

NSS

FLANGE

SN: A10001--UP

1шт.

12

NSS

WASHER

SN: A10001--UP

2шт.

13

NSS

BOLT

SN: A10001--UP

2шт.

14

27544KF

COUPLING, 90 DEGREE SPLIT FLANGE KING

SN: A10001--UP

1шт.

15

15502KF

BOLT (5/8 IN x 1-1/2 IN)

SN: A10001--UP

2шт.

16

10771KF

WASHER, SAE FLAT (5/8 IN PL GR9)

SN: A10001--UP

2шт.

17

17179

O-RING, AUXILIARY PUMP PILOT

SN: A10001--UP

1шт.

18

28453KF

HOSE, SUCTION (2032-32-0-0)

SN: A10001--UP

1шт.

19

23095KF

BOLT (5/8 IN x 2 IN)

SN: A10001--UP

4шт.

20

27545KF

ADAPTER, 45 DEGREE NIPPLE KING (2 IN)

SN: A10001--UP

1шт.

21

27541KF

TUBE, SUCTION

SN: A10001--UP

1шт.

22

PUMP, 71CC AUXILIARY (SEE FIG. H4000-01A0 )

SN: A10001--UP

-1шт.

Выбрано товаров: 23
