Запчасти Komatsu 445FXL-1 H-A ГИДРОЛИНИЯ ОСНОВН. УПРАВЛЯЮЩ. КЛАПАН ВОЗВРАТ. ЛИНИЯ ГИДРАВЛИКА

1

17909KF

CONNECTOR ASSEMBLY (W46K-20-20)

SN: A10001--UP

1шт.

2

15389KF

O-RING (1-1/2 IN SF - CODE 61/62)

SN: A10001--UP

1шт.

3

17055KF

ELBOW, 90 DEGREE (20-20 C50L0-S)

SN: A10001--UP

1шт.

4

83532KF

HOSE ASSEMBLY (2051-20-200S-200S-W)

SN: A10001--UP

1шт.

5

17344KF

CONNECTOR, STRAIGHT (FF1852T-2020S)

SN: A10001--UP

1шт.

6

10402KF

BOLT (3/8 IN x 1-1/4 IN)

SN: A10001--UP

2шт.

7

10802KF

WASHER (0.375 IN)

SN: A10001--UP

2шт.

8

22674KF

BRACKET, RETURN OIL MANIFOLD

SN: A10001--UP

1шт.

9

MANIFOLD, LOGIC VALVE ( SEE FIG. H0050- 01A0 )

SN: A10001--UP

-1шт.

10

20444KF

BOLT (10 MM - 1.5P x 35 MM)

SN: A10001--UP

4шт.

11

18950KF

PLUG (6408-HHP-20)

SN: A10001--UP

2шт.
