Запчасти Komatsu 445FXL-1 H-A ГИДРОЛИНИЯ DISC SAW PRESSURE И ВОЗВРАТНАЯ ЛИНИЯ - НАВЕСН. ОБОРУД ГИДРАВЛИКА

|$0

22758KF

CONNECTOR ASSEMBLY, FLANGE PAD (1 IN CODE 61)

SN: A10001--UP

1шт.

1

15377

O-RING (1 IN SF)

SN: A10001--UP

1шт.

2

NSS

FLANGE

SN: A10001--UP

1шт.

3

NSS

WASHER

SN: A10001--UP

2шт.

4

NSS

BOLT

SN: A10001--UP

2шт.

5

15225KF

CONNECTOR, STRAIGHT (FF1852T-1616S)

SN: A10001--UP

2шт.

6

28458KF

HOSE ASSEMBLY (4087-16-160S-1609-W)

SN: A10001--UP

1шт.

7

28533KF

HOSE ASSEMBLY (4040-16-160S-160S-WS225)

SN: A10001--UP

1шт.

8

15559KF

WASHER, SAE FLAT (5/16 IN)

SN: A10001--UP

2шт.

9

10824KF

BOLT (5/16 IN x 2-1/2 IN)

SN: A10001--UP

2шт.

10

15228KF

ELBOW, 90 DEGREE (FF1868T-1616S)

SN: A10001--UP

1шт.

11

28534KF

HOSE ASSEMBLY (2025-16-160S-1604-W WS225)

SN: A10001--UP

1шт.

12

18950KF

PLUG (6408-HHP-20)

SN: A10001--UP

1шт.

13

29148KF

ELBOW, 45 DEGREE

SN: A10001--UP

1шт.

14

VALVE, SAW STOP ( SEE FIG. H5100-01A0 )

SN: A10001--UP

-1шт.
