Запчасти Komatsu 445FXL-1 H-A ГИДРОЛИНИЯ FILL НАСОС - ВОЗВРАТ. МАСЛ. КОЛЛЕКТОР ГИДРАВЛИКА

Схема запчастей Komatsu 445FXL-1 - H-A ГИДРОЛИНИЯ FILL НАСОС - ВОЗВРАТ. МАСЛ. КОЛЛЕКТОР ГИДРАВЛИКА
1
16
25
2
14
19
20
15
3
21
7
4
22
7
26
6
12
8
6
5
10
11
24
9
13
18
23
17

Артикул

Название

Примечание

Количество

1

17670KF

ELBOW, 90 DEGREE (FF2098T-1212S)

SN: A10001--UP

1шт.

2

28801KF

HOSE ASSEMBLY (2028-08-080S-0809-W)

SN: A10001--UP

1шт.

3

15115KF

CONNECTOR, STRAIGHT (FF1852T-0810S)

SN: A10001--UP

1шт.

4

24588KF

HOSE ASSEMBLY (2033-08-080S-0809)

SN: A10001--UP

1шт.

5

10402KF

BOLT (3/8 IN x 1-1/4 IN)

SN: A10001--UP

2шт.

6

15528KF

WASHER

SN: A10001--UP

4шт.

7

10813KF

NUT, NYLOCK (0.375 IN)

SN: A10001--UP

2шт.

|$7

4A1-62-10060

BRACKET ASSEMBLY, FILL PUMP

SN: A10001--UP

1шт.

8

81272KF

ADAPTOR, STR (12MORS-8M PIPE)

SN: A10001--UP

1шт.

9

4A1-62-10070

BRACKET

SN: A10001--UP

1шт.

10

01640-20508

WASHER

SN: A10001--UP

2шт.

11

02100-10313

BOLT, SOCKET HEAD

SN: A10001--UP

2шт.

12

17307FKF

DISCONNECT, QUICK

SN: A10001--UP

1шт.

13

17323MKF

COVER, QUICK DISCONNECT DUST

SN: A10001--UP

1шт.

N/I

16126KF

NIPPLE

SN: A10001--UP

1шт.

N/I

10320KF

ELBOW, 90 DEGREE SWIVEL (1501-4-4)

SN: A10001--UP

3шт.

N/I

28583KF

VALVE, PANEL MOUNT BALL

SN: A10001--UP

1шт.

14

15605KF

BOLT (5/16 IN x 3/4 IN)

SN: A10001--UP

4шт.

15

15606KF

WASHER, LOCK (5/16 IN)

SN: A10001--UP

4шт.

16

15152KF

CONNECTOR, STR (FF1852T-1212S)

SN: A10001--UP

1шт.

17

16297KF

ELBOW, 90 DEGREE SWIVEL (FF2098T-0808S)

SN: A10001--UP

1шт.

18

28617KF

BRACKET

SN: A10001--UP

1шт.

19

11707KF

BOLT

SN: A10001--UP

1шт.

20

15528KF

WASHER

SN: A10001--UP

1шт.

21

16499KF

BRACKET, FILL PUMP SWITCH

SN: A10001--UP

1шт.

22

25104KF

SWITCH, LIMIT (DOOR/FILL PUMP)

SN: A10001--UP

1шт.

23

28860KF

HOSE ASSEMBLY (2096-08-08FP-08MP-SP)

SN: A10001--UP

1шт.

24

MANIFOLD, RETURN LINE ( SEE FIG. H0259- 01A0 )

SN: A10001--UP

-1шт.

25

PUMP, FILL ( SEE FIG. H0113-01A0 )

SN: A10001--UP

-1шт.

26

81272KF

ADAPTER, STR (12MORS-8M PIPE)

SN: A10001--UP

1шт.

Выбрано товаров: 30
