Запчасти Komatsu 445FXL-1 H-A ГИДРОЛИНИЯ МАСЛООХЛАДИТЕЛЬ И ВОЗВРАТ. МАСЛ. КОЛЛЕКТОР - ГИДР. БАК. ГИДРАВЛИКА

1

24257KF

ELBOW, 45 DEGREE (FF2068T-2424S)

SN: A10001--UP

1шт.

2

29149KF

HOSE ASSEMBLY (2087-24-240S-240S-W)

SN: A10001--UP

1шт.

3

15228KF

ELBOW, 90 DEGREE (FF1868T-1616S)

SN: A10001--UP

1шт.

4

22438KF

ELBOW, 90 DEGREE (849L-TT0-24x24)

SN: A10001--UP

1шт.

5

83533KF

HOSE ASSEMBLY (2039-16-16OS-16OS)

SN: A10001--UP

1шт.

6

17323FKF

COVER, QUICK DISCONNECT DUST

SN: A10001--UP

1шт.

7

15434KF

CAP (FF9863-08S)

SN: A10001--UP

1шт.

8

10402KF

BOLT (3/8 IN x 1-1/4 IN)

SN: A10001--UP

2шт.

9

10802KF

WASHER (0.375 IN)

SN: A10001--UP

4шт.

10

16034

PLUG, COOLER SUBASSEMBLY (FF9767-16S)

SN: A10001--UP

1шт.

11

MANIFOLD, RETURN LINE ( SEE FIG. H0259- 01A0 )

SN: A10001--UP

-1шт.

12

85858KF

NIPPLE, QUICK DISCONNECT

SN: A10001--UP

1шт.

13

19290KF

BUSHING, REDUCER (6410-10-8)

SN: A10001--UP

1шт.

14

85857KF

ELBOW, 90 DEGREE STR THRD SWIVEL

SN: A10001--UP

1шт.
