Запчасти Komatsu 445FXL-1 H9-A ОСНОВН. УПРАВЛЯЮЩ. КЛАПАН TEST ЛИНИЯ ГИДРАВЛИКА

1

15124KF

CONNECTOR, STR (FF1852T-0406S)

SN: A10001--UP

2шт.

2

15145KF

ELBOW, 90 DEGREE SWIVEL (FF2098T-0404S)

SN: A10001--UP

1шт.

3

16541KF

CONNECTOR, STR (FF1852T-0404S)

SN: A10001--UP

1шт.

4

MANIFOLD, PRESSURE CHECK ( SEE FIG. H0253-01A0 )

SN: A10001--UP

-1шт.

5

10731KF

BOLT (0.375 IN x 1-1/2 IN)

SN: A10001--UP

2шт.

6

16037KF

TAP, GAUGE PORT (0.025)

SN: A10001--UP

1шт.

7

SUPPORT, HYDRAULIC TANK ( SEE FIG. H0115- 01A0 )

SN: A10001--UP

-1шт.

8

83066KF

HOSE ASSEMBLY (6061-02-040S-0404)

SN: A10001--UP

1шт.

9

15528KF

WASHER, SAE FLAT (3/8 IN)

SN: A10001--UP

2шт.
