Запчасти Komatsu 445FXL-1 H-A IMPLEMENT НАСОС - ОСНОВН. УПРАВЛЯЮЩ. КЛАПАН HARVESTING PRESSURE ЛИНИЯ PROCESSOR № И № ГИДРАВЛS ONLY ГИДРАВЛИКА

|$0

18397KF

CONNECTOR KIT, FLANGE PAD (W48-16-16U CODE 62)

SN: A10001--UP

1шт.

1

NSS

FLANGE

SN: A10001--UP

1шт.

2

15389KF

O-RING (1-1/2 IN SF - CODE 61/62)

SN: A10001--UP

1шт.

3

NSS

WASHER

SN: A10001--UP

4шт.

4

18954KF

BOLT, ALLEN (12 MM - 1.75 x 40 MM)

SN: A10001--UP

4шт.

5

22266KF

CONNECTOR, TEE

SN: A10001--UP

1шт.

6

27360KF

HOSE ASSEMBLY (4059-20-200S-2004-W)

SN: A10001--UP

1шт.

|$7

15114KF

FLANGE KIT, SPLIT

SN: A10001--UP

1шт.

7

NSS

FLANGE, SPLIT

SN: A10001--UP

1шт.

8

NSS

O-RING, FLANGE

SN: A10001--UP

1шт.

9

NSS

WASHER

SN: A10001--UP

2шт.

10

NSS

BOLT

SN: A10001--UP

2шт.

11

26146KF

BUSHING, REDUCER (6410-16-20)

SN: A10001--UP

1шт.

12

20992KF

PLUG

SN: A10001--UP

4шт.

|$14

15111KF

FLANGE KIT, SPLIT (1 IN CODE 61)

SN: A10001--UP

4шт.

13

NSS

FLANGE

SN: A10001--UP

1шт.

14

NSS

O-RING

SN: A10001--UP

1шт.

15

NSS

WASHER

SN: A10001--UP

4шт.

16

959239

BOLT

SN: A10001--UP

4шт.

17

PUMP, IMPLEMENT ( SEE FIG. H0301-01A0 )

SN: A10001--UP

-1шт.
