Запчасти Komatsu 445FXL-1 B-A ГЛУШИТЕЛЬ КОМПОНЕНТЫ ДВИГАТЕЛЯ

1

18822KF

MUFFLER

SN: A10001--UP

1шт.

2

PANEL, MUFFLER ( SEE FIG. J0100-01A0 )

SN: A10001--UP

-1шт.

3

27364KF

ELBOW, EXHAUST

SN: A10001--UP

1шт.

4

16259

CLAMP, TURBO EXHAUST

SN: A10001--UP

1шт.

5

10813KF

NUT, LOCK (0.375 IN)

SN: A10001--UP

6шт.

6

10802KF

WASHER (0.375 IN)

SN: A10001--UP

2шт.

7

18416KF

BOLT (10 MM x 1.5P x 25 MM)

SN: A10001--UP

2шт.

8

27365KF

BRACKET, TOP MUFFLER

SN: A10001--UP

1шт.

9

18830KF

CLAMP, MUFFLER MOUNT

SN: A10001--UP

1шт.

10

10402KF

BOLT (3/8 IN x 1-1/4 IN)

SN: A10001--UP

4шт.

11

15528KF

WASHER, SAE FLAT (3/8 IN)

SN: A10001--UP

10шт.

12

16734KF

RETAINER, RUBBER MUFFLER

SN: A10001--UP

2шт.

13

16572KF

RUBBER, MUFFLER MOUNTING

SN: A10001--UP

1шт.
