Запчасти Komatsu 445FXL-1 H-A IMPLEMENT НАСОС PRESSURE ЛИНИЯ - ОСНОВН. УПРАВЛЯЮЩ. КЛАПАН ГИДРАВЛИКА

|$0

18397KF

CONNECTOR KIT, FLANGE PAD (W48-16-16U CODE 62)

SN: A10001--UP

1шт.

1

NSS

FLANGE

SN: A10001--UP

1шт.

2

NSS

O-RING

SN: A10001--UP

1шт.

3

NSS

WASHER

SN: A10001--UP

4шт.

4

18954KF

BOLT (12 MM - 1.75 x 40 MM)

SN: A10001--UP

4шт.

5

17055KF

ELBOW, 90 DEGREE (20-20 C50L0-S)

SN: A10001--UP

1шт.

6

27360KF

HOSE ASSEMBLY (4056-20-2005-20F4-WS)

SN: A10001--UP

1шт.

7

26146KF

BUSHING, REDUCER (6410-16-20)

SN: A10001--UP

1шт.

|$8

15114KF

FLANGE KIT, SPLIT (1-1/4 IN CODE 62)

SN: A10001--UP

1шт.

8

NSS

FLANGE, SPLIT

SN: A10001--UP

1шт.

9

NSS

O-RING, FLANGE

SN: A10001--UP

1шт.

10

NSS

WASHER

SN: A10001--UP

2шт.

11

NSS

BOLT

SN: A10001--UP

2шт.

12

15584KF

PLUG (6408-HHP-12)

SN: A10001--UP

1шт.

13

PUMP, IMPLEMENT (SEE FIG. H0301-01A0 )

SN: A10001--UP

-1шт.
