Запчасти Komatsu 445FXL-1 H-A IMPLEMENT НАСОС КРЕПЛЕНИЕ ГИДРАВЛИКА

Схема запчастей Komatsu 445FXL-1 - H-A IMPLEMENT НАСОС КРЕПЛЕНИЕ ГИДРАВЛИКА
2
1
3
4
5
22
21
23
6
8
7
10
9
24
11
20
12
13
19
14
18
15
14
16
17

Артикул

Название

Примечание

Количество

1

GEAR BOX, TRIPLE PUMP DRIVE ( SEE FIG. H0240-01A0 )

SN: A10001--UP

-1шт.

2

15842KF

FILTER, IMPLEMENT SCREEN

SN: A10001--UP

1шт.

3

15448KF

O-RING (5-1/2 IN OD)

SN: A10001--UP

1шт.

4

22462KF

PLATE, INTERMEDIATE SUCTION PORT

SN: A10001--UP

1шт.

5

22441KF

VALVE, BUTTERFLY SHUT OFF

SN: A10001--UP

1шт.

6

23095KF

BOLT (5/8 IN x 2 IN)

SN: A10001--UP

4шт.

|$6

22639KF

FLANGE KIT, SPLIT (3 IN)

SN: A10001--UP

1шт.

7

NSS

FLANGE

SN: A10001--UP

2шт.

8

18695KF

O-RING

SN: A10001--UP

1шт.

9

NSS

BOLT (M16 x 46 MM)

SN: A10001--UP

4шт.

10

NSS

WASHER

SN: A10001--UP

4шт.

11

27767KF

TUBE (3 IN)

SN: A10001--UP

1шт.

12

15574KF

BUSHING, REDUCER (5406-4-2)

SN: A10001--UP

1шт.

13

22302KF

VALVE, PROBALYSER

SN: A10001--UP

1шт.

14

27909KF

CLAMP, CONSTANT TORQUE

SN: A10001--UP

2шт.

15

27894KF

HOSE, SUCTION (3 IN)

SN: A10001--UP

1шт.

16

27769KF

TUBE, SUCTION (3 IN)

SN: A10001--UP

1шт.

|$17

18306KF

FLANGE KIT, SPLIT (3 IN)

SN: A10001--UP

1шт.

17

15502KF

BOLT (5/8 IN x 1-1/2 IN)

SN: A10001--UP

1шт.

18

10771KF

WASHER, SAE FLAT (5/8 IN PL GR9)

SN: A10001--UP

4шт.

19

NSS

FLANGE

SN: A10001--UP

1шт.

20

18695KF

O-RING

SN: A10001--UP

1шт.

21

10776KF

NUT, HEX (3/4 IN)

SN: A10001--UP

4шт.

22

15550KF

WASHER, SAE FLAT (3/4 IN)

SN: A10001--UP

4шт.

23

15442KF

O-RING

SN: A10001--UP

1шт.

24

PUMP, IMPLEMENT ( SEE FIG. H0301-01A0 )

SN: A10001--UP

-1шт.

|$26

26

-1шт.

|$27

F1 - USED TO TAKE OIL SAMPLES.

27

-1шт.

Выбрано товаров: 28
