Запчасти Komatsu 445FXL-1 H7-A ПОВОРОТН. КОЛЛЕКТОР ГИДРАВЛИКА

|$0

26400KF

MANIFOLD, ROTARY

SN: A10001--UP

1шт.

1

NSS

PISTON

SN: A10001--UP

1шт.

2

NSS

RING, ANTI-FRICTION

SN: A10001--UP

1шт.

3

NSS

MANIFOLD, HOUSING

SN: A10001--UP

1шт.

4

NSS

O-RING

SN: A10001--UP

12шт.

5

NSS

SEAL, SLIPPER

SN: A10001--UP

12шт.

6

NSS

SEAL, U-CUP

SN: A10001--UP

2шт.

7

NSS

SCREW

SN: A10001--UP

4шт.

8

NSS

SCREW

SN: A10001--UP

6шт.

9

NSS

WIRE

SN: A10001--UP

2шт.

10

NSS

COVER, END

SN: A10001--UP

1шт.

11

NSS

RING, ANTI-FRICTION

SN: A10001--UP

1шт.

12

NSS

SEAL, DUST

SN: A10001--UP

1шт.

13

NSS

NUT, SELF-LOCKING

SN: A10001--UP

2шт.

14

NSS

SPACER, FLANGE

SN: A10001--UP

1шт.

15

NSS

O-RING

SN: A10001--UP

1шт.

16

NSS

SCREW

SN: A10001--UP

2шт.

17

NSS

SCREW

SN: A10001--UP

2шт.

18

NSS

POST, BRUSH HOLDER

SN: A10001--UP

3шт.

19

NSS

COVER, ALUMINUM

SN: A10001--UP

1шт.

20

NSS

NUT, SELF-LOCKING

SN: A10001--UP

5шт.

21

NSS

COVER, ELECTRIC

SN: A10001--UP

1шт.

22

NSS

STUD

SN: A10001--UP

3шт.

23

NSS

BRUSH ASSEMBLY

SN: A10001--UP

4шт.

24

NSS

RING, PLATED CONDUCTING

SN: A10001--UP

2шт.

25

NSS

TUBING, FLANGE PORT

SN: A10001--UP

1шт.

26

NSS

WASHER, RUBBER

SN: A10001--UP

3шт.

27

NSS

HOLDER, BRUSH

SN: A10001--UP

2шт.

28

NSS

SPACER, INSULATING

SN: A10001--UP

4шт.

29

NSS

O-RING

SN: A10001--UP

1шт.

30

NSS

RING, INSULATOR

SN: A10001--UP

3шт.

31

NSS

CONNECTOR, STRAIN RELIEF

SN: A10001--UP

1шт.

32

NSS

CONNECTOR, STRAIN RELIEF

SN: A10001--UP

1шт.

33

NSS

RING, BRONZE SUPPORT

SN: A10001--UP

2шт.

34

NSS

SCREW

SN: A10001--UP

2шт.

35

NSS

NUT

SN: A10001--UP

1шт.

36

NSS

O-RING, SQUARE

SN: A10001--UP

5шт.

37

NSS

SEAL, HIGH PRESSURE OIL

SN: A10001--UP

5шт.

|$38

23246

REPAIR KIT, ROTARY MANIFOLD SEAL

SN: A10001--UP

1шт.

|$39

26666

CLUSTER ASSEMBLY, COMPLETE ELECTRICAL

SN: A10001--UP

1шт.

|$40

40

-1шт.

|$41

F3 - WHEN REPLACING THE ROTARY MANIFOLD FOR THE FIRST TIME, OTHER PARTS MUST BE REPLACED AND ADDED AT THE SAME TIME. PLEASE SEE FOOTNOTE ON FIGURE NUMBER D0200-02A0.

43

-1шт.

|$42

F3 - WHEN REPLACING THE ROTARY MANIFOLD FOR THE FIRST TIME, OTHER PARTS MUST BE REPLACED AND ADDED AT THE SAME TIME. PLEASE SEE FOOTNOTE ON FIGURE NUMBER D0200-02A0.

43

-1шт.

|$43

F3 - WHEN REPLACING THE ROTARY MANIFOLD FOR THE FIRST TIME, OTHER PARTS MUST BE REPLACED AND ADDED AT THE SAME TIME. PLEASE SEE FOOTNOTE ON FIGURE NUMBER D0200-02A0.

43

-1шт.
