Запчасти Komatsu 445FXL-1 B9-A ВОЗДУХООЧИСТИТЕЛЬ КРЕПЛЕНИЕ КОМПОНЕНТЫ ДВИГАТЕЛЯ

1

24295KF

TUBE, AIR CLEANER EXTENSION (5 IN x 7 IN ID)

SN: A10001--UP

1шт.

2

15542KF

BOLT (3/8 IN x 3/4 IN)

SN: A10001--UP

4шт.

3

10802KF

WASHER (0.375 IN)

SN: A10001--UP

4шт.

4

18818

GUARD, AIR CLEANER BRUSH

SN: A10001--UP

1шт.

5

18910KF

ELBOW, RUBBER (5 IN x 6 IN)

SN: A10001--UP

1шт.

6

18828KF

CLAMP, STRAP BAND (6-3/4 IN)

SN: A10001--UP

1шт.

7

16249KF

CLAMP, STRAP BAND (5-1/2 IN)

SN: A10001--UP

2шт.

8

18816KF

CONNECTOR, AIR INTAKE

SN: A10001--UP

1шт.

9

26703KF

BOOT, RUBBER AIR INTAKE

SN: A10001--UP

1шт.

10

PANEL, AIR CLEANER ( SEE FIG. J0100-01A0 )

SN: A10001--UP

-1шт.

11

10813KF

NUT, LOCK (0.375 IN)

SN: A10001--UP

4шт.

12

16608

BOOT, AIR CLEANER DUST

SN: A10001--UP

1шт.

13

15831KF

ELBOW, RUBBER (4 IN x 5 IN)

SN: A10001--UP

1шт.

14

15697KF

CLAMP, STRAP BAND (4-1/2 IN)

SN: A10001--UP

1шт.

15

15528KF

WASHER, SAE FLAT (3/8 IN)

SN: A10001--UP

8шт.

16

16495KF

BOOT, RUBBER

SN: A10001--UP

1шт.

17

AIR CLEANER ( SEE FIG. B1410-01A0 )

SN: A10001--UP

-1шт.

18

11704KF

BUSHING (2-1/2 IN X 3 IN x 4-1/4 IN)

SN: A10001--UP

4шт.

19

19263KF

CLAMP

SN: A10001--UP

2шт.

20

10788KF

NUT, NYLOCK (5/16 IN)

SN: A10001--UP

2шт.

21

15591

BOLT (5/16 IN x 1-1/2 IN)

SN: A10001--UP

2шт.

22

28665KF

PLATE, AIR CLEANER GUARD SUPPORT

SN: A10001--UP

1шт.
