Запчасти Komatsu 445FXL-1 H-A ТРОЙН. НАСОС ПРИВОД КОРПУС ГИДРАВЛИКА

|$0

24099KF

BOX KIT, TRIPLE PUMP DRIVE GEAR

SN: A10001--UP

1шт.

1

18027

SEAL, SHAFT

SN: A10001--UP

1шт.

2

18388

SHAFT, DRIVE

SN: A10001--UP

1шт.

3

21300

BOLT, FLYWHEEL COVER

SN: A10001--UP

8шт.

4

21301

COVER, FLYWHEEL HOUSING

SN: A10001--UP

1шт.

5

18891

BEARING, FRONT INPUT GEAR

SN: A10001--UP

1шт.

6

24687

GEAR, INPUT

SN: A10001--UP

1шт.

7

18892

BEARING, REAR INPUT GEAR

SN: A10001--UP

1шт.

8

18371

DIPSTICK

SN: A10001--UP

1шт.

9

18372

TUBE, DIPSTICK

SN: A10001--UP

1шт.

10

21304

BREATHER

SN: A10001--UP

1шт.

11

11312

BUSHING, REDUCING

SN: A10001--UP

1шт.

12

15660KF

ELBOW, 90 DEGREE STR (1/2 IN)

SN: A10001--UP

1шт.

13

21305

HOUSING

SN: A10001--UP

1шт.

14

16892

BEARING, PUMP GEAR

SN: A10001--UP

6шт.

15

24688

GEAR, PUMP

SN: A10001--UP

3шт.

16

18292

ADAPTOR, PUMP PAD

SN: A10001--UP

1шт.

17

NSS

BUSHING

SN: A10001--UP

1шт.

18

10776KF

NUT

SN: A10001--UP

4шт.

19

18293

STUD, PUMP ADAPTOR

SN: A10001--UP

4шт.

20

NSS

BOLT

SN: A10001--UP

1шт.

21

21307

ADAPTOR, PUMP PAD

SN: A10001--UP

2шт.

22

21308

PLUG, MAGNETIC

SN: A10001--UP

2шт.

23

21309

PLUG

SN: A10001--UP

4шт.

24

18028

PLATE, DRIVE

SN: A10001--UP

1шт.
