Запчасти Komatsu GD825A-2E0 ГИДРАВЛ УПРАВЛЯЮЩ. КЛАПАН¤ ПРАВ. (5-СЕКЦИОНН.) (/)(№-) ГИДРАВЛИКА

|$0

235-60-35400

VALVE ASS'Y,HYD. CONTROL, R.H.

SN: 12023-UP

1шт.

|$$2

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.6215 TO 6217.

-1шт.

|$$3

THE UCHIDA YUATSU KIKI PART NUMBER IS THAT UC IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.

-1шт.

1

UC4100547969

BODY ASS'Y,FREE DRIFT

SN: 12023-UP

1шт.

2

UC4100547969

BODY ASS'Y,SCARIFIER

SN: 12023-UP

1шт.

3

UC4100547979

BODY ASS'Y,LEANING

SN: 12023-UP

1шт.

4

UC4100547988

BODY ASS'Y,ARTICULATE

SN: 12023-UP

1шт.

5

UC4100547997

BODY ASS'Y,DRAWBAR SIDE SHIFT

SN: 12023-UP

1шт.

|$$9

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.6216 AND 6217.

-1шт.

6

UC4100463541

COVER ASS'Y

SN: 12023-UP

1шт.

7

UC1100236728

COVER

SN: 12023-UP

1шт.

8

UC1801478216

PLUG

SN: 12023-UP

1шт.

9

UC1198273603

PLUG

SN: 12023-UP

1шт.

10

UC1301895001

PLUG

SN: 12023-UP

1шт.

11

UC1301896004

PLUG

SN: 12023-UP

1шт.

12

UC1100111876

ORIFICE

SN: 12023-UP

1шт.

13

UC1301148002

O-RING

SN: 12023-UP

3шт.

14

UC1301169009

O-RING

SN: 12023-UP

1шт.

15

UC1300149004

O-RING

SN: 12023-UP

1шт.

16

UC1300170008

O-RING

SN: 12023-UP

1шт.

17

UC1179043407

RING

SN: 12023-UP

1шт.

18

UC1179043508

RING

SN: 12023-UP

1шт.

19

UC1178286401

SHIM

SN: 12023-UP

4шт.

20

UC1100184773

COVER

SN: 12023-UP

1шт.

21

UC1163500002

BOLT,STUD

SN: 12023-UP

4шт.

22

UC1301996003

NUT

SN: 12023-UP

4шт.

23

UC1302060004

WASHER

SN: 12023-UP

4шт.
