Артикул
Название
Примечание
Количество
|1
6211-71-1470
INJECTION PUMP A.
SN: 17626-UP
1шт.
|$$2
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-B4A1 TO A4010-G4A1.
-1шт.
|$$3
THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.
-1шт.
|1
DK105407-5010
GOVERNOR ASS'Y
SN: 17626-UP
1шт.
|$$5
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-D4A1 AND A4010-E4A1.
-1шт.
2
DK154500-8120
COVER
SN: 17626-UP
1шт.
3
DK154321-0400
BUSHING
SN: 17626-UP
1шт.
4
DK154031-4300
SCREW
SN: 17626-UP
1шт.
5
DK139208-0400
NUT
SN: 17626-UP
1шт.
6
DK154036-0300
PLUG
SN: 17626-UP
1шт.
7
DK020106-5040
BOLT
SN: 17626-UP
2шт.
8
DK154010-0200
SCREW
SN: 17626-UP
1шт.
9
DK020106-3840
BOLT
SN: 17626-UP
4шт.
10
DK154063-7300
COVER
SN: 17626-UP
1шт.
11
DK029020-6210
BOLT
SN: 17626-UP
2шт.
12
DK020006-1640
BOLT
SN: 17626-UP
2шт.
14
DK154158-3420
CAPSULE,SPRING
SN: 17626-UP
1шт.
15
DK154011-1700
NUT
SN: 17626-UP
1шт.
21
DK016010-1640
RING,SNAP
SN: 17626-UP
2шт.
30
DK154347-4920
LEVER
SN: 17626-UP
1шт.
31
DK154367-0420
LEVER
SN: 17626-UP
1шт.
32
DK020006-1640
BOLT
SN: 17626-UP
1шт.
34
DK154322-0100
CAP
SN: 17626-UP
1шт.
40
DK154035-2000
NUT,CAP
SN: 17626-UP
1шт.
|1
6211-71-1470
INJECTION PUMP A.
SN: 17626-UP
1шт.
|$$2
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-B4A1 TO A4010-G4A1.
-1шт.
|$$3
THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.
-1шт.
|1
DK105407-5010
GOVERNOR ASS'Y
SN: 17626-UP
1шт.
|$$5
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-D4A1 AND A4010-E4A1.
-1шт.
2
DK154500-8120
COVER
SN: 17626-UP
1шт.
3
DK154321-0400
BUSHING
SN: 17626-UP
1шт.
4
DK154031-4300
SCREW
SN: 17626-UP
1шт.
5
DK139208-0400
NUT
SN: 17626-UP
1шт.
6
DK154036-0300
PLUG
SN: 17626-UP
1шт.
7
DK020106-5040
BOLT
SN: 17626-UP
2шт.
8
DK154010-0200
SCREW
SN: 17626-UP
1шт.
9
DK020106-3840
BOLT
SN: 17626-UP
4шт.
10
DK154063-7300
COVER
SN: 17626-UP
1шт.
11
DK029020-6210
BOLT
SN: 17626-UP
2шт.
12
DK020006-1640
BOLT
SN: 17626-UP
2шт.
14
DK154158-3420
CAPSULE,SPRING
SN: 17626-UP
1шт.
15
DK154011-1700
NUT
SN: 17626-UP
1шт.
21
DK016010-1640
RING,SNAP
SN: 17626-UP
2шт.
30
DK154347-4920
LEVER
SN: 17626-UP
1шт.
31
DK154367-0420
LEVER
SN: 17626-UP
1шт.
32
DK020006-1640
BOLT
SN: 17626-UP
1шт.
34
DK154322-0100
CAP
SN: 17626-UP
1шт.
40
DK154035-2000
NUT,CAP
SN: 17626-UP
1шт.
