Артикул
Название
Примечание
Количество
|$0
235-60-35300
VALVE ASS'Y,HYD. CONTROL, L.H.
SN: 12023-UP
1шт.
|$$2
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.6211 TO 6214.
-1шт.
|$$3
THE UCHIDA YUATSU KIKI PART NUMBER IS THAT UC IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.
-1шт.
1
UC4100548009
BODY ASS'Y,CIRCLE
SN: 12023-UP
1шт.
2
UC4100548019
BODY ASS'Y,POWER TILT
SN: 12023-UP
1шт.
3
UC4100547969
BODY ASS'Y,BLADE SIDE SHIFT
SN: 12023-UP
1шт.
4
UC4100548028
BODY ASS'Y,RIPPER
SN: 12023-UP
1шт.
5
UC4100548037
BODY ASS'Y,FREE DRIFT
SN: 12023-UP
1шт.
|$$9
THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.6212 TO 6214.
-1шт.
6
UC4100463541
COVER ASS'Y
SN: 12023-UP
1шт.
7
UC1100236728
COVER
SN: 12023-UP
1шт.
8
UC1801478216
PLUG
SN: 12023-UP
1шт.
10
UC1301895001
PLUG
SN: 12023-UP
1шт.
11
UC1301896004
PLUG
SN: 12023-UP
1шт.
12
UC1100111876
ORIFICE
SN: 12023-UP
1шт.
13
UC1301148002
O-RING
SN: 12023-UP
3шт.
14
UC1301169009
O-RING
SN: 12023-UP
1шт.
16
UC1300170008
O-RING
SN: 12023-UP
1шт.
17
UC1179043407
RING
SN: 12023-UP
1шт.
18
UC1179043508
RING
SN: 12023-UP
1шт.
19
UC1178286401
SHIM
SN: 12023-UP
4шт.
20
UC1100184773
COVER
SN: 12023-UP
1шт.
21
UC1163500002
BOLT,STUD
SN: 12023-UP
4шт.
22
UC1301996003
NUT
SN: 12023-UP
4шт.
23
UC1302060004
WASHER
SN: 12023-UP
4шт.
Выбрано товаров: 27
