Запчасти Komatsu GD755-5R МАРКИРОВКА (№-) МАРКИРОВКА, ИРАН-АНГЛ.

|$0

23C-53-62110

Plate

SN: 10001-UP

1шт.

1

Plate, Fuse Box 3

SN: 10001-UP

1шт.

2

Plate, Fuse Box 2

SN: 10001-UP

1шт.

3

Plate, Fuse Box 1

SN: 10001-UP

1шт.

4

Plate, Lamp

SN: 10001-UP

1шт.

5

Plate, MANU

SN: 10001-UP

1шт.

6

Plate, T/C AUTO

SN: 10001-UP

1шт.

7

Plate, Blade Accumulator

SN: 10001-UP

1шт.

8

Plate, Lifter Lock Pin

SN: 10001-UP

1шт.

9

Plate, Head Lamp

SN: 10001-UP

1шт.

10

Plate, Blind Plate

SN: 10001-UP

1шт.

11

Plate, Wiper

SN: 10001-UP

1шт.

12

Plate, Service Mode 1

SN: 10001-UP

1шт.

13

Plate, Service Mode 2

SN: 10001-UP

1шт.

14

Plate, Switch Mark (ON/OFF)

SN: 10001-UP

3шт.

15

Plate, Creep Mode

SN: 10001-UP

1шт.

16

Plate, Diff Lock

SN: 10001-UP

1шт.

17

Plate, Free Diff

SN: 10001-UP

1шт.

18

Plate, Washer Tank Front Up

SN: 10001-UP

1шт.

19

Plate, Washer Tank Front Low/Rear

SN: 10001-UP

1шт.

20

Plate, Lighting

SN: 10001-UP

1шт.

21

Plate, Rabbit Mark Set

SN: 10001-UP

1шт.

22

Plate, Turtle Mark Resume

SN: 10001-UP

1шт.

22

23C-53-62230

Plate

SN: 10001-UP

1шт.

23

09683-0000A

Plate, Symbol, Starting Switch Control

SN: 10001-UP

1шт.

24

235-53-11610

Plate, Head Lamp,L.H.

SN: 10001-UP

1шт.

25

232-43-18281

Plate, Mark, Drawber Shift

SN: 10001-UP

1шт.

26

232-735-1340

Plate, Mark, Power Tilt

SN: 10001-UP

1шт.

27

234-53-32321

Plate, Mark, Circle Revolution

SN: 10001-UP

1шт.

28

237-54-13211

Plate, Mark, Blade Lift

SN: 10001-UP

2шт.

29

237-54-13221

Plate, Mark, Leaning

SN: 10001-UP

1шт.

30

237-54-13231

Plate, Mark, Blade Shift

SN: 10001-UP

1шт.

31

234-53-32330

Plate, Articulate

SN: 10001-UP

1шт.

32

23A-53-11550

Decal, Mark, Turn Signal

SN: 10001-UP

1шт.

33

23C-53-63370

Plate, Starting Support

SN: 10001-UP

1шт.

34

23C-53-61170

Plate, Heater Switch of Air Conditioner

SN: 10001-UP

1шт.

35

09651-A0881

Plate, Warning, Read Manual Before Operating

SN: 10001-UP

1шт.

36

09801-E0881

Plate, Danger, High Voltage Hazard

SN: 10001-UP

1шт.

37

09802-E0640

Plate, Warning, Before Operating and Traveling

SN: 10001-UP

1шт.

38

23C-53-63170

Plate, Caution, Starting

SN: 10001-UP

1шт.

39

09819-00400

Plate, Warning, Bank Control

SN: 10001-UP

1шт.

40

09845-00480

Plate, Caution, Blast Site

SN: 10001-UP

1шт.

40

23C-53-62310

Plate

SN: 10001-UP

1шт.

41

09637-A0640

Plate, Service Instruction, Air Cleaner

SN: 10001-UP

1шт.

42

09669-0000E

Plate, Symbol, Fuel Filler

SN: 10001-UP

1шт.

43

09669-0000C

Plate, Symbol, Oil Filler, Hydraulic Tank

SN: 10001-UP

1шт.

44

09669-0000C

Plate, Symbol, Oil Filler, T/M

SN: 10001-UP

1шт.

45

09653-A0641

Plate, Warning, High Temperature

SN: 10001-UP

2шт.

46

09806-E1201

Plate, Danger, Keep Away from Machine

SN: 10001-UP

1шт.

47

09808-A1681

Plate, Warning, Battery Cables

SN: 10001-UP

2шт.

48

09667-A0481

Plate, Caution, Rotating Object

SN: 10001-UP

2шт.

49

23B-53-71270

Plate, Don't Walk

SN: 10001-UP

2шт.

50

6217-71-6860

Plate, Caution, Specified Fuel Filter Use

SN: 10001-UP

1шт.

51

23C-53-51121

Decal, Machine Model

SN: 10001-UP

2шт.

52

09690-P0900

Plate, Komatsu Logo

SN: 10001-UP

2шт.

53

09690-F0315

Plate, Komatsu Logo

SN: 10001-UP

1шт.

54

04418-13060

Screw

SN: 10001-UP

4шт.

55

23C-53-62140

Lubrication Chart

SN: 10001-UP

1шт.

56

234-53-26310

Tag, Caution, Coolant Density

SN: 10001-UP

1шт.

57

232-785-1411

Plate, Ripper

SN: 10001-UP

1шт.

58

09960-00602

Mark, Tie Down Point

SN: 10001-UP

4шт.

59

09960-01201

Mark, Lift Point and Tie Down Point Marks

SN: 10001-UP

2шт.

60

09960-00801

Mark, Lift Point

SN: 10001-UP

2шт.

61

09659-A057B

Plate, Warning, Explosion Hazard

SN: 10001-UP

2шт.

62

09963-A1640

Tag, Danger, Do Not Operate

SN: 10001-UP

1шт.

63

23C-53-62270

Plate, Warning, Shift Down Capable Speed

SN: 10001-UP

1шт.

64

23B-53-71260

Plate, Mark, Leaning

SN: 10001-UP

1шт.

65

09162-E0881

Plate, Danger, Keep Off

SN: 10001-UP

2шт.

66

09161-C0881

Plate, Warning, Articulation Lock

SN: 10001-UP

1шт.

67

09620-A2000

Plate, Name, ROPS/FOPS (Limited Supply)

SN: 10001-UP

1шт.

68

09620-A3000

Plate, Warning, ROPS/FOPS

SN: 10001-UP

1шт.

69

205-00-72430

Rivet

SN: 10001-UP

4шт.

70

22B-54-22490

Sheet, Non-Slip

SN: 10001-UP

2шт.

71

23C-53-62170

Sheet, Non-Slip

SN: 10001-UP

2шт.

72

23C-53-62160

Sheet, Non-Slip

SN: 10001-UP

1шт.

73

09602-10002

Plate, Name (Limited Supply)

SN: 10001-UP

1шт.

74

09806-E0883

Plate, Danger, Keep Away from Machine

SN: 10001-UP

1шт.

75

14X-98-35181

Plate, Reflector

SN: 10001-UP

2шт.

75

23C-53-62130

Plate, RPM Set Switch

SN: 10001-UP

1шт.

76

Plate, Auto Mode

SN: 10001-UP

1шт.

77

Plate, Manual Mode

SN: 10001-UP

1шт.
