Запчасти Komatsu GD750A-1 ТРАНСМИССИЯ И ГИДРОТРАНСФОРМАТОР ПРИВОД TRAIN

|$0

1434 856 H91

TRANSMISSION & TORQUE CONVERTER

1шт.

1

CONVERTER ASSEMBLY (SEE PG 07-034)

-29шт.

2

COVER, FRONT (SEE PG 07-032)

-29шт.

3

PUMP, CHARGE (SEE PG 07-036)

-29шт.

4

SHAFT, 1ST STAGE (SEE PG 07-038)

-29шт.

5

CLUTCH PACK - 2ND STAGE (SEE PG 07-040)

-29шт.

6

CLUTCH PACK - 3RD STAGE (SEE PG 07-042)

-29шт.

7

CLUTCH PACK - 4TH STAGE (SEE PG 07-044)

-29шт.

8

CLUTCH PACK - 5TH STAGE (SEE PG 07-046)

-29шт.

9

CLUTCH PACK - 6TH STAGE (SEE PG 07-048)

-29шт.

10

CASE ASSEMBLY, MAIN (SEE PG 07-030)

-29шт.

11

1438 261 H1

BOLT

12шт.

12

1437 727 H1

RING, ADAPTOR

1шт.

13

1437 670 H1

SLEEVE, PILOT

1шт.

14

1437 668 H1

SHAFT, INPUT

1шт.

15

25 465 R1

O-RING

1шт.

16

22 414 R1

O-RING

1шт.

17

VALVE, LOCKUP CONVERTER (SEE PG 07-052)

-29шт.

18

VALVE, TRANSMISSION CONTROL (SEE PG 07-054)

-29шт.

19

YOKE (SEE PG 07-056)

-29шт.

20

SHAFT, OUTPUT (SEE PG 07-058)

-29шт.

21

1437 669 H91

PLATE, DRIVE ASSY

1шт.

22

1244 194 H1

RING

1шт.

23

1237 733 H1

BOLT

12шт.

24

1437 761 H1

ADAPTOR, STEERING PUMP

1шт.

25

1438 259 H1

BOLT

4шт.

N/I

1437 745 H1

SENSOR, TEMPERATURE

1шт.

|$27

1438 243 H1

O-RING

1шт.

|$28

144 099 H1

FILLER PIPE

1шт.

|$29

931 431 R1

BOLT

2шт.
