Запчасти Komatsu GD750A-1 INTERNAL ТАБЛИЧКИS GD7A РАЗНОЕ

|$0

1439 366 H91

DECALS, MODEL

-1шт.

1

1436 411 H1

THROTTLE

1шт.

2

1436 412 H1

THROTTLE

1шт.

3

127 859

TAG

1шт.

4

163 344

RING, KEY

1шт.

5

1439 643 H1

CIRCUIT BREAKER LOCATIONS

1шт.

6

1435 996 H1

RIVET

1шт.

7

NS

PLATE, PRODUCT IDENTIFICATION NUMBER

1шт.

8

1439 405 H1

CAUTION

1шт.

9

CYLINDER LOCK PIN (SEE PG 11-002)

-29шт.

10

DIFFERENTIAL LOCK (SEE PG 11-002)

-29шт.

11

1435 456 H3

DECAL, SWITCH PANEL

1шт.

12

1439 406 H1

ICON, BLADE FLOAT

1шт.

13

1439 408 H1

ICON, BLADE CUSHION

1шт.

14

1439 414 H1

ICON, BLADE LIGHT

1шт.

15

1439 412 H1

ICON, REAR LIGHT

1шт.

16

1439 414 H1

ICON, BEACON

1шт.

17

1439 411 H1

ICON, HEADLIGHT

1шт.

18

NSS

DECAL, TEMPERATURE CONTROL/FAN SPEED

1шт.

|$$20

-1шт.

|$20

F1 - ITEM 11 ADHERES ATOP THE CONSOLE BUT DOES NOT INCLUDE

-1шт.

|$21

ITEMS 12 THRU 17, WHICH ARE ICONS FOR THE ROCKER SWITCHES.

-1шт.

|$$23

-1шт.

|$23

F2 - ICON LOCATED ON THE INDIVIDUAL ROCKER SWITCH.

-1шт.

|$$25

-1шт.
