Запчасти Komatsu GD750A-1 ТЕРМОСТАТ & КОЖУХ СИСТЕМА ОХЛАЖДЕНИЯ

|$0

1307 095 H91

HOUSING, THERMOSTAT

1шт.

1

1307 096 H1

HOUSING, THERMOSTAT

1шт.

2

1238 500 H1

SEAL, THERMOSTAT

1шт.

3

1240 101 H1

PLUG, PIPE (1/8 NPTF)

1шт.

4

6732-11-1910

PLUG, PIPE (1/2 NPTF)

2шт.

5

6732-11-1920

PLUG, PIPE (3/4 NPTF)

1шт.

6

1307 644 H1

SUPPORT, THERMOSTAT HOUSING

1шт.

|$7

6732-21-5540

PLUG, PIPE (3/8 NPT)

1шт.

7

1246 118 H91

PLUG, THREADED (9/16-18 UNF)

1шт.

8

1246 119 H1

O-RING

1шт.

9

1246 120 H1

PLUG, THREADED

1шт.

10

1296 841 H1

SEAL, RECTANGULAR RING

1шт.

11

1277 843 H1

HOSE, PLAIN

1шт.

12

1246 515 H2

BOLT (M10x1.50x145)

2шт.

13

1304 954 H1

GASKET, SUPPORT

1шт.

14

1240 426 H1

CLAMP, HOSE

2шт.

15

1294 287 H1

BOLT (M10x1.50x35)

3шт.

16

1307 094 H1

BOLT (M10x1.50x172)

2шт.

17

1238 601 H2

THERMOSTAT

1шт.

18

1307 093 H1

BOLT (M10x1.50x120)

1шт.
