Запчасти Komatsu GD750A-1 ВОДЯНАЯ ПОМПА СИСТЕМА ОХЛАЖДЕНИЯ

|$0

1295 271 H91

ASSEMBLY, WATER PUMP

1шт.

1

1240 443 H2

O-RING

1шт.

2

1246 568 H1

GASKET, CONNECTION

1шт.

3

1238 047 H1

BEARING, BALL

1шт.

4

1294 219 H1

O-RING

1шт.

5

1246 575 H1

RING, RETAINING

1шт.

6

1239 655 H2

SEAL, WATER PUMP

1шт.

7

1268 144 H1

RING, RETAINING

1шт.

8

1246 576 H1

SEAL, OIL

1шт.

9

1246 579 H1

IMPELLER, WATER PUMP

1шт.

10

1294 220 H1

SHAFT, WATER PUMP

1шт.

11

1246 580 H1

GEAR, WATER PUMP

1шт.

12

1294 221 H1

BODY, WATER PUMP

1шт.

13

1294 222 H1

O-RING

1шт.

14

1294 005 H1

BOLT (M10x1.50x25)

3шт.

15

6732-11-1910

PLUG, PIPE (1/2 NPT)

1шт.

16

6742-01-1460

PLUG, PIPE (1 NPT)

1шт.

17

1246 536 H1

WASHER, PLAIN (M8)

2шт.

18

1246 584 H1

CONNECTION, WATER TRANSFER

1шт.

19

1246 160 H1

BOLT (M10x1.50x30)

3шт.

20

6732-21-5160

BOLT

2шт.

21

1307 125 H1

COVER, WATER PUMP

1шт.

22

1267 723 H91

NIPPLE, COUPLING

2шт.

23

1246 119 H1

O-RING

1шт.

|$24

1246 118 H91

PLUG, THREADED

2шт.

24

1246 120 H1

PLUG, THREADED

1шт.

25

1246 119 H1

O-RING

1шт.

|$27

1294 224 H91

KIT, WATER PUMP REPAIR

1шт.

|$$29

-1шт.

|$29

F1 - ITEMS INCLUDED IN WATER PUMP REPAIR KIT.

-1шт.

|$$31

-1шт.

|$$32

-1шт.

|$32

R1 - REMANUFACTURED ASSEMBLY AVAILABLE; REFER TO REMANUFACTURED

-1шт.

|$33

ASSEMBLIES CATALOG.

-1шт.
