Запчасти Komatsu GD750A-1 БЛОК ЦИЛИНДРОВ БЛОК ЦИЛИНДРОВ

|$0

1295 191 H92

BLOCK ASSEMBLY, CYLINDER

1шт.

1

1296 769 H1

BLOCK, CYLINDER

1шт.

2

1246 122 H1

DOWEL, PIN - No. 4 only

2шт.

3

1238 448 H1

PLUG, RETAINER

1шт.

4

1239 318 H1

WASHER, PLAIN

1шт.

5

1239 319 H1

DISC, VALVE

1шт.

6

1239 320 H1

SPRING, BYPASS VALVE

1шт.

7

1294 031 H1

BUSHING, CAMSHAFT

7шт.

8

6732-61-2240

PLUG, PIPE - (1/4 NPT)

2шт.

9

1246 121 H1

SEAT, PRESSURE REG VALVE

1шт.

|$10

1246 125 H91

KIT, MAIN BEARING CAP - No. 4 only

1шт.

10

1294 116 H1

CAP, MAIN BEARING - No. 4 only

1шт.

11

1246 127 H1

PIN, ROLL

2шт.

10

1246 128 H1

CAP, MAIN BEARING - No. 1,2,3,5,6,7

6шт.

12

NSS

BOLT

14шт.

13

1246 117 H2

STUD (M10x1.50x50MM)

7шт.

14

1240 051 H1

DOWEL, PIN (5/16x1/2 INCH)

1шт.

15

1246 112 H1

DOWEL, PIN (7/16x1 INCH)

2шт.

16

6736-21-1820

PLUG, EXPANSION (1.00 INCH)

4шт.

17

1239 144 H1

PLUG, EXPANSION (.387MM)

9шт.

18

1246 114 H1

DOWEL, PIN (6.00x12.00MM)

3шт.

19

6732-11-1910

PLUG, PIPE (1/2 NPT)

1шт.

20

1246 116 H1

DOWEL, RING (19.23MM)

3шт.

20

1246 134 H1

DOWEL, PIN (USED WHEN HYD DRIVE IS NOT REQ.)

3шт.

|$24

1246 118 H91

PLUG, THREADED (9/16 - 18 INCH)

4шт.

21

1246 120 H1

PLUG, THREADED

1шт.

22

1246 119 H1

O-RING

1шт.

|$27

1246 131 H91

PLUG, THREADED (3/4-16 INCH)

1шт.

23

1246 132 H1

PLUG, THREADED

1шт.

24

6735-21-4160

O-RING

1шт.

25

1296 124 H1

SENSOR, VISCOSITY

1шт.

26

1246 124 H1

WASHER, PLAIN

14шт.

27

1296 126 H1

PLUNGER, PRESSURE REGULATOR

1шт.

28

1239 195 H1

SPRING, COMPRESSION

1шт.

29

1246 137 H1

PLUG, RETAINER

1шт.
