Запчасти Komatsu GD750A-1 INCH MOLDBOARD КРЕПЛЕНИЕED ОБОРУД-Е

|$0

1437 966 H91

MOLDBOARD ASSEMBLY - 1 IN X 24 IN X 14 FT

1шт.

|$1

1437 967 H91

MOLDBOARD ASSEMBLY - 1 IN X 24 IN X 16 FT

1шт.

1

1437 931 H91

MOLDBOARD WELDMENT - 14 FT

1шт.

|$3

1437 967 H91

MOLDBOARD WELDMENT - 16 FT

1шт.

2

45 493 A

BOLT, PLOW - DOME HEAD

12шт.

3

01643-32060

WASHER, FLAT

12шт.

4

25 529 R1

NUT, HEX

12шт.

5

1437 923 H1

BIT, REVERSIBLE END

2шт.

6

1280 305 H1

EDGE, CUTTING - 3/4 IN X 8 IN X 7 FT

2шт.

|$9

1280 318 H1

EDGE, CUTTING - 3/4 IN X 8 IN X 8 FT

2шт.

|$10

1280 320 H1

EDGE, CUTTING - 1 IN X 8 IN X 8 FT

2шт.

7

45 490 A

BOLT, PLOW - DOME HEAD

28шт.

8

01643-32060

WASHER, FLAT

28шт.

9

25 529 R1

NUT, HEX

28шт.

10

07048-01815

PLUG, CAP

8шт.

|$18

-1шт.

|$16

F1 - NOT INCLUDED IN MOLDBOARD ASSEMBLIES;

-1шт.

|$17

MUST BE ORDERED SEPARATELY

-1шт.
