Запчасти Komatsu GD750A-1 ПОДЪЕМ. ОТВАЛА АККУМУЛЯТОР ASSEMBLY ГИДРАВЛS

|$0

1435 237 H91

BLADE LIFT ACCUMULATOR ASSEMBLY

1шт.

1

ACCUMULATOR (SEE PG 10-054)

-29шт.

2

1436 983 H91

HARNESS, ACCUMULATOR

1шт.

3

1439 817 H1

CABLE TIE, DOUBLE LOOP

1шт.

4

1439 227 H92

BRACKET, BOTTLE

2шт.

5

1436 693 H1

PLATE, ACCUMULATOR

1шт.

6

WB 0089

TEE-SWIVEL

2шт.

|$7

WA 0014

O-RING

2шт.

7

VALVE, LIFT CYLINDER CUSHION (SEE PG 10-090)

-29шт.

8

70 969

UNION

2шт.

9

1439 817 H1

CABLE TIE, CLOSED LOOP

2шт.

10

1436 691 H1

BRACKET, ACCUMULATOR

4шт.

11

01010-80820

BOLT

8шт.

12

01643-30823

WASHER

8шт.

|$20

-1шт.

|$15

F1 - WHEN THIS OPTION IS ORDERED FROM THE FACTORY, THIS

-1шт.

|$16

PART IS WELDED TO THE FRAME AND NOT SERVICEABLE. HOWEVER,

-1шт.

|$17

IF THIS OPTION IS DESIRED AFTER THE MACHINE LEAVES THE

-1шт.

|$18

FACTORY, THIS PIECE CAN BE ORDERED AND WELDED TO THE

-1шт.

|$19

FRAME.

-1шт.
