Запчасти Komatsu GD705A-4A-N НАСОС ТРАНСМИССИИ СИЛОВАЯ ПЕРЕДАЧА

|1

234-60-65300

PUMP ASS'Y

SN: 13001-UP

1шт.

|$$2

THE KAYABA KOGYO PART NUMBER IS THAT KB IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.

-1шт.

1

KB20132-60620

COVER

SN: 13001-UP

1шт.

2

0

PLATE

SN: 13001-UP

1шт.

3

KB20132-60422

FLANGE

SN: 13001-UP

1шт.

|4

KBB530B-00006

GEAR ASS'Y

SN: 13001-UP

1шт.

4

0

GEAR,DRIVE

SN: 13001-UP

1шт.

5

0

GEAR,DRIVEN

SN: 13001-UP

1шт.

6

KB20131-60720

PLATE

SN: 13001-UP

2шт.

7

0

SEAL (KIT)

SN: 13001-UP

2шт.

8

0

RING (KIT)

SN: 13001-UP

2шт.

9

KB20131-61402

BOLT

SN: 13001-UP

4шт.

10

KB20131-61801

WASHER

SN: 13001-UP

4шт.

11

0

SEAL,OIL (KIT)

SN: 13001-UP

1шт.

12

0

RING,SNAP (KIT)

SN: 13001-UP

1шт.

|$$16

SERVICE KIT

-1шт.

KIT

KB2013A-60012

SEAL KIT,TRANSMISSION PUMP

SN: 13001-UP

1шт.
