Запчасти Komatsu GD675-5 МАРКИРОВКА, (/) (№-) МАРКИРОВКА, АНГЛ., PICTORIAL ТИП

1

09161-C0881

Plate, Warning, Articulation Lock

SN: 55001-UP

1шт.

2

09162-E0881

Plate, Danger, Keep Off

SN: 55001-UP

2шт.

3

09637-A0640

Plate, Service Instruction, Air Cleaner

SN: 55001-UP

1шт.

4

09649-03012

Plate, Notice, Engine Shutdown

SN: 55001-UP

1шт.

5

09651-A0841

Plate, Warning, Read Manual Before Operating

SN: 55001-UP

1шт.

6

09653-A0641

Plate, Warning, High Temperature

SN: 55001-UP

1шт.

7

09664-70001

Plate, Danger, Battery

SN: 55001-UP

2шт.

8

09653-A0641

Plate, Warning, High Temperature

SN: 55001-UP

1шт.

9

09669-0000E

Plate, Symbol, Fuel Filler

SN: 55001-UP

1шт.

10

09669-0000C

Plate, Symbol, Oil Filler

SN: 55001-UP

1шт.

11

09683-0000A

Plate, Symbol, Starting Switch Control

SN: 55001-UP

1шт.

12

09690-P0900

Plate, Komatsu Logo

SN: 55001-UP

2шт.

13

09690-F0400

Plate, Komatsu Logo

SN: 55001-UP

1шт.

14

09802-E0640

Plate, Warning, Before Operating and Traveling

SN: 55001-UP

1шт.

15

09808-A1201

Plate, Warning, Battery Cables

SN: 55001-UP

1шт.

16

09806-E0883

Plate, Danger, Keep Away from Machine

SN: 55001-UP

1шт.

17

09960-00801

Mark, Lift Point

SN: 55001-UP

2шт.

18

09960-00602

Mark, Tie Down Point

SN: 55001-UP

3шт.

19

09960-01201

Mark, Lift Point and Tie Down Point Marks

SN: 55001-UP

2шт.

20

09963-A1640

Tag, Danger, Do Not Operate

SN: 55001-UP

1шт.

21

232-43-18281

Plate, Mark, Drawber Shift

SN: 55001-UP

1шт.

22

232-735-1340

Plate, Mark, Power Tilt

SN: 55001-UP

1шт.

23

234-53-32321

Plate, Mark, Circle Revolution

SN: 55001-UP

1шт.

24

234-53-32330

Plate, Articulate

SN: 55001-UP

1шт.

25

09667-A0880

Plate, Caution, Rotating Object

SN: 55001-UP

2шт.

26

237-54-13211

Plate, Mark, Blade Lift

SN: 55001-UP

2шт.

27

237-54-13221

Plate, Mark, Leaning

SN: 55001-UP

1шт.

28

237-54-13231

Plate, Mark, Blade Shift

SN: 55001-UP

1шт.

29

09659-A057B

Plate, Warning, Explosion Hazard

SN: 55001-UP

4шт.

30

232-785-1411

Plate, Ripper

SN: 55001-UP

1шт.

31

23A-53-11550

Decal, Mark, Turn Signal

SN: 55001-UP

1шт.

32

23B-53-71170

Plate, Caution, Shift Down Capable Speed

SN: 55001-UP

1шт.

33

23B-53-71180

Plate, Caution, MT/AT Velocity Range

SN: 55001-UP

1шт.
