|$3
23B-952-5010
CAB ASS'Y,(W/FRONT L. AND REAR WIPER)
SN: 11001-UP
1шт.
|$4
23B-952-1021
CAB ASS'Y,(W/FRONT L. AND REAR WIPER)
SN: 10001-11000
1шт.
|$$3
THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.K0210-01A0 TO K0210-17A4
-1шт.
|$6
23B-952-6290
CAB ASS'Y,(KOMTRAX) (TURKEY)
SN: 11162-UP
1шт.
|$$5
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.K0210-01A6 TO K0210-21A6
-1шт.
1
08180-12411
WIPER MOTOR ASS'Y
SN: 10001-UP
1шт.
2
01023-60512
SCREW
SN: 10001-UP
2шт.
3
20T-54-84840
ARM,WIPER
SN: 10001-UP
1шт.
4
20T-54-74990
BLADE,WIPER
SN: 10001-UP
1шт.
5
22T-55-11630
NOZZLE ASS'Y
SN: 10001-UP
1шт.
6
23A-952-1541
HOSE
SN: 10001-UP
1шт.
7
23A-952-1460
BRACKET
SN: 10001-UP
1шт.
8
01010-80620
BOLT
SN: 10001-UP
4шт.
9
01643-30623
WASHER
SN: 10001-UP
4шт.
10
20T-06-71410
SWITCH,REAR WIPER
SN: 10001-UP
1шт.
11
23A-952-1550
HOSE, 2000MM
SN: 10001-UP
1шт.
12
120-Y79-5760
VALVE,CHECK
SN: 10001-UP
1шт.
