Артикул
Название
Примечание
Количество
|$0
6150-71-1570
INJECTION PUMP A.
SN: 19761-UP
1шт.
|$$2
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0452,0463,0464,0472 AND 0482.
-1шт.
|$$3
THE NIPPON DENSO PART NUMBER IS THAT ND IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.
-1шт.
|$3
ND190800-0310
GOVERNOR ASS'Y
SN: 19761-UP
1шт.
|$$5
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0463 AND 0464.
-1шт.
1
ND090810-0390
HOUSING
SN: 19761-UP
1шт.
2
ND090878-0040
PLATE
SN: 19761-UP
1шт.
3
ND091024-0031
SCREW,ADJUSTING
SN: 19761-UP
2шт.
4
ND090901-0200
LEVER ASS'Y,TENSION
SN: 19761-UP
1шт.
5
ND090930-0490
LEVER ASS'Y,CONTROL
SN: 19761-UP
1шт.
6
ND090894-0010
E-RING
SN: 19761-UP
1шт.
7
ND948053-0051
NUT
SN: 19761-UP
2шт.
8
ND090970-0350
SHACKLE ASS'Y
SN: 19761-UP
1шт.
9
ND949130-0050
KEY,WOODRUFF
SN: 19761-UP
1шт.
10
ND090840-0520
FLYWEIGHT ASS'Y
SN: 19761-UP
1шт.
11
ND949015-0500
WASHER, 2.5MM,SPRING
SN: 19761-UP
1шт.
14
ND090868-0040
PLATE,THRUST
SN: 19761-UP
1шт.
15
ND90567-30000
RING
SN: 19761-UP
1шт.
16
ND949013-4090
WASHER, 0.1MM
SN: 19761-UP
-2шт.
16
ND949013-4060
WASHER, 0.2MM
SN: 19761-UP
-2шт.
16
ND949013-4070
WASHER, 0.3MM
SN: 19761-UP
-2шт.
16
ND949013-4080
WASHER, 0.4MM
SN: 19761-UP
-2шт.
16
ND949013-4100
WASHER, 1.0MM
SN: 19761-UP
-2шт.
17
ND090992-0480
SPRING,CONTROL
SN: 19761-UP
1шт.
|$26
ND090910-1760
ADAPTER ASS'Y
SN: 19761-UP
1шт.
18
ND090911-0020
SCREW,ADAPTER
SN: 19761-UP
1шт.
19
ND090919-0341
ADAPTER
SN: 19761-UP
1шт.
20
ND090918-0110
SPRING,GOVERNOR
SN: 19761-UP
1шт.
21
ND090918-2081
SPRING,GOVERNOR
SN: 19761-UP
1шт.
22
ND949013-3890
WASHER, 0.1MM
SN: 19761-UP
-2шт.
22
ND949013-4110
WASHER, 0.2MM
SN: 19761-UP
-2шт.
23
ND949013-4450
WASHER, 0.1MM
SN: 19761-UP
-2шт.
23
ND949013-3750
WASHER, 0.3MM
SN: 19761-UP
-2шт.
24
ND090923-0011
NUT
SN: 19761-UP
1шт.
25
ND090224-0140
PLUG
SN: 19761-UP
1шт.
26
ND090119-0040
GASKET,PUMP BODY
SN: 19761-UP
1шт.
28
ND090993-0280
SPRING,START
SN: 19761-UP
1шт.
29
ND090245-0230
SCREW
SN: 19761-UP
1шт.
31
ND949047-0620
BOLT
SN: 19761-UP
2шт.
32
ND91418-06201
BOLT
SN: 19761-UP
2шт.
33
ND91518-06161
BOLT
SN: 19761-UP
4шт.
|$0
6150-71-1570
INJECTION PUMP A.
SN: 19761-UP
1шт.
|$$2
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0452,0463,0464,0472 AND 0482.
-1шт.
|$$3
THE NIPPON DENSO PART NUMBER IS THAT ND IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.
-1шт.
|$3
ND190800-0310
GOVERNOR ASS'Y
SN: 19761-UP
1шт.
|$$5
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0463 AND 0464.
-1шт.
1
ND090810-0390
HOUSING
SN: 19761-UP
1шт.
2
ND090878-0040
PLATE
SN: 19761-UP
1шт.
3
ND091024-0031
SCREW,ADJUSTING
SN: 19761-UP
2шт.
4
ND090901-0200
LEVER ASS'Y,TENSION
SN: 19761-UP
1шт.
5
ND090930-0490
LEVER ASS'Y,CONTROL
SN: 19761-UP
1шт.
6
ND090894-0010
E-RING
SN: 19761-UP
1шт.
7
ND948053-0051
NUT
SN: 19761-UP
2шт.
8
ND090970-0350
SHACKLE ASS'Y
SN: 19761-UP
1шт.
9
ND949130-0050
KEY,WOODRUFF
SN: 19761-UP
1шт.
10
ND090840-0520
FLYWEIGHT ASS'Y
SN: 19761-UP
1шт.
11
ND949015-0500
WASHER, 2.5MM,SPRING
SN: 19761-UP
1шт.
14
ND090868-0040
PLATE,THRUST
SN: 19761-UP
1шт.
15
ND90567-30000
RING
SN: 19761-UP
1шт.
16
ND949013-4090
WASHER, 0.1MM
SN: 19761-UP
-2шт.
16
ND949013-4060
WASHER, 0.2MM
SN: 19761-UP
-2шт.
16
ND949013-4070
WASHER, 0.3MM
SN: 19761-UP
-2шт.
16
ND949013-4080
WASHER, 0.4MM
SN: 19761-UP
-2шт.
16
ND949013-4100
WASHER, 1.0MM
SN: 19761-UP
-2шт.
17
ND090992-0480
SPRING,CONTROL
SN: 19761-UP
1шт.
|$26
ND090910-1760
ADAPTER ASS'Y
SN: 19761-UP
1шт.
18
ND090911-0020
SCREW,ADAPTER
SN: 19761-UP
1шт.
19
ND090919-0341
ADAPTER
SN: 19761-UP
1шт.
20
ND090918-0110
SPRING,GOVERNOR
SN: 19761-UP
1шт.
21
ND090918-2081
SPRING,GOVERNOR
SN: 19761-UP
1шт.
22
ND949013-3890
WASHER, 0.1MM
SN: 19761-UP
-2шт.
22
ND949013-4110
WASHER, 0.2MM
SN: 19761-UP
-2шт.
23
ND949013-4450
WASHER, 0.1MM
SN: 19761-UP
-2шт.
23
ND949013-3750
WASHER, 0.3MM
SN: 19761-UP
-2шт.
24
ND090923-0011
NUT
SN: 19761-UP
1шт.
25
ND090224-0140
PLUG
SN: 19761-UP
1шт.
26
ND090119-0040
GASKET,PUMP BODY
SN: 19761-UP
1шт.
28
ND090993-0280
SPRING,START
SN: 19761-UP
1шт.
29
ND090245-0230
SCREW
SN: 19761-UP
1шт.
31
ND949047-0620
BOLT
SN: 19761-UP
2шт.
32
ND91418-06201
BOLT
SN: 19761-UP
2шт.
33
ND91518-06161
BOLT
SN: 19761-UP
4шт.
Выбрано товаров: 90
