Запчасти Komatsu 6D125-1Z ТОПЛ. НАСОС (РЕГУЛЯТОР) (/)(№7-) ТОПЛИВН. СИСТЕМА

|$0

6150-71-2721

INJECTION PUMP A.

SN: 40363-UP

1шт.

|$1

0

INJECTION PUMP A.

SN: 26170-40362

1шт.

|$$3

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.0451,0461,0462,0471 AND 0481.

-1шт.

|$$4

THE NIPPON DENSO PART NUMBER IS THAT ND IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.

-1шт.

|$4

ND190800-1361

GOVERNOR ASS'Y

SN: 40363-UP

1шт.

|$5

ND190800-1360

GOVERNOR ASS'Y

SN: 26170-40362

1шт.

|$$7

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.0461 AND 0462.

-1шт.

1

ND090811-0810

HOUSING,GOVERNOR

SN: 26170-UP

1шт.

2

ND090878-0030

PLATE

SN: 26170-UP

1шт.

3

ND091024-0031

SCREW,ADJUST

SN: 26170-UP

2шт.

4

ND090901-0200

LEVER ASS'Y,TENSION

SN: 26170-UP

1шт.

5

ND090930-0510

LEVER ASS'Y,CONTROL

SN: 26170-UP

1шт.

6

ND90400-02101

E-RING

SN: 26170-UP

1шт.

7

ND948053-0051

NUT

SN: 26170-UP

2шт.

8

ND091046-0010

SLIDER,SUPPORT

SN: 26170-UP

1шт.

9

ND090970-0170

SHACKLE ASS'Y

SN: 26170-UP

1шт.

10

ND949130-0050

KEY,WOODRUFF

SN: 26170-UP

1шт.

11

ND090840-0520

FLYWEIGHT ASS'Y

SN: 26170-UP

1шт.

12

ND949015-0500

WASHER, 2.5MM,SPRING

SN: 26170-UP

1шт.

13

ND090844-0010

NUT

SN: 26170-UP

1шт.

14

ND090860-0200

SLEEVE SUB ASS'Y,GOVERNOR

SN: 26170-UP

1шт.

15

ND090868-0040

PLATE,THRUST

SN: 26170-UP

1шт.

16

ND90567-30000

RING

SN: 26170-UP

1шт.

17

ND949013-4090

WASHER, 0.1MM

SN: 26170-UP

-2шт.

17

ND949013-4060

WASHER, 0.2MM

SN: 26170-UP

-2шт.

17

ND949013-4070

WASHER, 0.3MM

SN: 26170-UP

-2шт.

17

ND949013-4080

WASHER, 0.4MM

SN: 26170-UP

-2шт.

17

ND949013-4100

WASHER, 1.0MM

SN: 26170-UP

-2шт.

18

ND090992-0480

SPRING,CONTROL

SN: 26170-UP

1шт.

19

ND090993-0260

SPRING,START

SN: 26170-UP

1шт.

|$30

ND090910-1760

ADAPTER ASS'Y

SN: 26170-UP

1шт.

20

ND090911-0020

SCREW,ADAPTER

SN: 26170-UP

1шт.

21

ND090919-0341

ADAPTER

SN: 26170-UP

1шт.

22

ND090918-0110

SPRING,GOVERNOR

SN: 26170-UP

1шт.

23

ND090918-2081

SPRING,GOVERNOR

SN: 26170-UP

1шт.

24

ND949013-3890

WASHER, 0.1MM

SN: 26170-UP

-2шт.

24

ND949013-4110

WASHER, 0.2MM

SN: 26170-UP

-2шт.

25

ND949013-4450

WASHER, 0.1MM

SN: 26170-UP

-2шт.

25

ND949013-3750

WASHER, 0.3MM

SN: 26170-UP

-2шт.

26

ND090923-0011

NUT,ADAPTER LOCK

SN: 26170-UP

1шт.

27

ND090224-0140

PLUG

SN: 26170-UP

1шт.

28

ND949018-1550

WASHER

SN: 26170-UP

1шт.

29

ND090823-0240

GASKET

SN: 26170-UP

1шт.

30

ND090823-0180

GASKET

SN: 26170-UP

1шт.

31

ND090245-0230

SCREW

SN: 26170-UP

1шт.

32

ND090222-0120

WASHER

SN: 26170-UP

1шт.

33

ND91518-08221

BOLT

SN: 26170-UP

1шт.

34

ND91418-06161

BOLT

SN: 26170-UP

6шт.
