Запчасти Komatsu S6D105-1NN ТУРБОНАГНЕТАТЕЛЬ ГОЛОВКА ЦИЛИНДРОВ

|$0

6138-82-8201

TURBOCHARGER ASS'Y,(T04B59)

SN: 82904-UP

1шт.

|$1

0

TURBOCHARGER ASS'Y,(T04B59-39)

SN: 81519-82903

1шт.

|$$3

THE AIR RESEARCH PART NUMBER IS THAT GA IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.

-1шт.

1

GA409518-0608

HOUSING,BLOWER

SN: 81519-UP

1шт.

2

GA408105-5376

CORE ASS'Y

SN: 82904-UP

1шт.

2

GA408105-5227

CORE ASS'Y

SN: 81519-82903

1шт.

3

GA407875-0000

CLAMP

SN: 81519-UP

3шт.

4

GA407876-0000

PLATE,LOCK

SN: 81519-UP

3шт.

5

GA400298-0301

BOLT

SN: 81519-UP

6шт.

6

GA406908-0002

CLAMP

SN: 81519-UP

3шт.

7

GA406909-0000

PLATE,LOCK

SN: 81519-UP

3шт.

8

GA400450-0001

BOLT

SN: 81519-UP

6шт.

9

GA410401-0037

HOUSING,TURBINE

SN: 81519-UP

1шт.
