Запчасти Komatsu GD655-5 ТРАНСМИССИЯ, 4 SPEED МУФТА ТРАНСМИССИЯ

|1

23B-13-70000

Transmission Assembly

SN: B40001-UP

1шт.

|1

23B-15-72040

Clutch Assembly

SN: B40001-UP

1шт.

1

23B-15-72241

Shaft,Output

SN: B40001-UP

1шт.

2

56D-15-29790

Plug

SN: B40001-UP

1шт.

3

23B-15-72590

Housing,4th

SN: B40001-UP

1шт.

4

714-23-12690

Piston, Range

SN: B40001-UP

1шт.

5

419-15-12140

Ring, Snap

SN: B40001-UP

1шт.

6

714-12-19711

Disc, T=2.2mm

SN: B40001-UP

6шт.

7

714-16-19730

Plate, T=1.7mm, Separate

SN: B40001-UP

7шт.

8

56D-15-12710

Spring, Wave

SN: B40001-UP

6шт.

9

714-12-12610

Plate, End

SN: B40001-UP

1шт.

10

714-16-19220

Seal Ring, (Kit : K01)

SN: B40001-UP

1шт.

11

714-07-19320

Seal Ring, (Kit : K01)

SN: B40001-UP

1шт.

12

714-08-19570

Washer, Thrust

SN: B40001-UP

2шт.

13

714-23-19430

Bearing, Needle

SN: B40001-UP

1шт.

14

714-23-19210

Seal Ring, (Kit : K01)

SN: B40001-UP

2шт.

15

714-23-12710

Spacer

SN: B40001-UP

1шт.

16

23B-15-72550

Gear,Output

SN: B40001-UP

1шт.

17

04064-08530

Ring, Snap

SN: B40001-UP

1шт.

18

06040-06315

Bearing

SN: B40001-UP

1шт.

19

06040-06313

Bearing

SN: B40001-UP

1шт.

20

419-15-12122

Ring, (Kit : K01)

SN: B40001-UP

2шт.
